www.weller.eu April 29, 2008 NEW: WD 1000HPT The New Generation of High Power Tools Weller Info No. 15 The WD 1000HPT station features Weller s new 120 W High Power Tool, our new WP 120 soldering iron. This iron is ideal for soldering on challenging circuit boards with heat sinks and big soldering joints that cause large dissipation in heat transfer. The Weller WD 1000HPT station is specifically designed for your soldering operations which need a combination of high energy and maximum precision. The WD 1000HPT comprises - The WP 120 Soldering Iron The new WP 120 High Power Tool offers twice as much power and efficiency in a small and ergonomic pencil design. Combining a compact, powerful heating element with a replaceable soldering tip the WP 120 guarantees best life cycle cost at dynamic performance. The rapid transfer of heat into the soldering tip is quickly and precisely controlled with sophisticated electronics which allows the WP 120 s compact design to cope with big and difficult solder joints even at barely accessible joints. Also ideal for HF shield plates or solar panel manufacturing. The WD 1M Power Unit Our well established microprocessor controlled WD 1M has a number of in built special functions as preset temperatures, individual settings for setback, USB connectivity, which make it ideally suited for use in production, rework and laboratory environments. From now on we equip all WD 1Ms additionally with new advanced software specially designed for this new WP 120 High Power Tool. The WDH 10T Stop + Go Iron Safety Rest Special tip life saving functions are automatically activated when you place the soldering iron into the WDH 10T safety rest. This is an easy and effective way for you to increase tip life particularly when using lead free solder. By removing the iron from the rest the tip temperature is restored immediately to the set working level. WELLER NEWS No.1 / Seite 2 von 2 Weller Info No. 15 / Page 2 of 2 April 29, 2008 Technical Data WD 1000HPT Dimensions (L x W x H mm): 134 x 108 x 147 Mains voltage supply: 230 V / 120 V / 50/60 Hz Power: 160W Safety class: I (power unit), III (soldering iron) Temperature control: 50C 450C (150F 850F) Temperature accuracy: 9C ( 17F) Temperature stability: 5C ( 9F) Soldering tip leakage resistance:< 2 (tip-to-ground) Soldering tip leakage current: < 2 mV (tip-to-ground) Scope of delivery soldering kit WD 1000HPT Power unit WD 1M Soldering iron WP 120 Safety rest WDH 10T Order-no.: 005 34 166 99 Order-no. UK: 005 34 163 99 Order-no. USA: WD1000HPT (available August 2008) XT-tips for WP 120 Order no Model Type Width Height Length 005 44 701 99 XT AL Chisel 1,6 mm 1,0 mm 39 mm 005 44 702 99 XT M Chisel 3,2 mm 1,2 mm 39 mm 005 44 703 99 XT A Chisel 1,6 mm 0,7 mm 36 mm 005 44 704 99 XT B Chisel 2,4 mm 0,8 mm 36 mm 005 44 705 99 XT C Chisel 3,2 mm 0,8 mm 36 mm 005 44 706 99 XT D Chisel 4,6 mm 0,8 mm 34,5 mm 005 44 707 99 XT E Chisel 5,9 mm 1,2 mm 34,5 mm Published by Author: Marketing, Besigheim Contact: Stephan Hofmann Phone: +49 (0) 7143 580 145 Global Product Manager Electronic Fax: +49 (0) 7143 580 113 Stephan.Hofmann CooperIndustries.com Cooper Tools GmbH Carl Benz Str. 2 D-74354 Besigheim Copyright 2008, Cooper Tools GmbH
