MHDPPK25-DB25P-K MH Connectors

MHDPPK Series Plastic Hood & D-Sub Connector Kit S&F Description Stamped & Formed D-Sub contacts, selective Gold plated contacts, Tin plated solder buckets Black plastic clamshell design Quick snap together locking system Straight cable entry Will accommodate up to 11.5mm diameter cable Cable clamp is secured with 2 screws 4-40 UNC jackscrews Specification D-Sub Hood No. Contacts 9, 15 & 25 Voltage Rating 250V Kit Type D-Sub connector kit Current Rating 5 Amps Housing Material Polyamide, UL recognised Contact Resistance 25m Max Cable Entry Straight Insulation Resistance 1000M Cable OD Up to 11.5mm Operating Temperature -55C to 105C The Kit Contains Shell Tin plated Steel Backshell Halves x 2 D-Sub connector x 1 Insulator Material Glass filled Polyester Strain relief screws x 2 Contact Material Copper alloy Housing screws x 2 4-40 UNC jackscrews x 2 Contact Plating Selective Gold over Nickel, solder Metallised plastic bucket: Tin plated x 1 compression insertsHood Dimentions Male Dimentions Female Dimensions Size A B C D E 09 15 25 09 15 25 31.50mm 24.99mm 34.00mm 15.00mm 8.00mm A 16.92mm 25.25mm 38.96mm A 30.88mm 39.20mm 53.02mm 09 1.240 0.984 1.339 0.591 0.315 B 24.99mm 33.32mm 47.04mm B 24.88mm 33.30mm 47.04mm 40.00mm 33.32mm 34.00mm 15.00mm 11.50mm C 30.81mm 39.14mm 53.04mm C 19.28mm 27.75mm 41.30mm 15 1.575 1.312 1.339 0.591 0.453 D 19.23mm 27.56mm 41.30mm D 18.94mm 27.50mm 41.20mm 53.50mm 47.04mm 40.00mm 15.00mm 11.50mm E 1.0mm 1.0mm 1.0mm 25 2.106 1.852 1.575 0.591 0.453 F 10.8mm 10.8mm 10.8mm G 2.7mm 2.7mm 2.7mm H 5.84mm 5.84mm 5.84mm Part No. Norcomp Part No. Positions Male/Female Contact Type Hood Part No. Norcomp Part No. D-Sub Part No. Norcomp Part No. Stamped & MHDPPK9-DB9P-K 999-009-C10S102 9 Pin Male MHDPPK-09-K 972-009-015R011 MHDB9SP 171-009-102L001 Formed Stamped & MHDPPK15-DB15P-K 999-015-C10S102 15 Pin Male MHDPPK-15-K 972-015-015R011 MHDB15SP 171-015-102L001 Formed Stamped & MHDPPK25-DB25P-K 999-025-C10S102 25 Pin Male MHDPPK-25-K 972-025-015R011 MHDB25SP 171-025-102L001 Formed Stamped & MHDPPK9-DB9S-K 999-009-C10S202 9 Pin Female MHDPPK-09-K 972-009-015R011 MHDB9SS 171-009-202L001 Formed Stamped & MHDPPK15-DB15S-K 999-015-C10S202 15 Pin Female MHDPPK-15-K 972-015-015R011 MHDB15SS 171-015-202L001 Formed Stamped & MHDPPK25-DB25S-K 999-025-C10S202 25 Pin Female MHDPPK-25-K 972-025-015R011 MHDB25SS 171-025-202L001 Formed
