3S4YRMKW1XD Omron

Motor Driven Card Reader/Writer 3S4YR-MKW Versatile Hybrid Reader/Writer Handles Both Magnetic and IC Cards Durable 4-wheel, 2-belt drive with roller accommodates discrepancies in card thickness to accept warped or bent cards Metal blade shutter prevents tampering Compact size and light weight allow easy installation in any terminal Two integrated chip station positions available Adjustable to card thicknesses of 0.20 mm, 0.40 mm, and 0.76 mm (PET, paper, or PVC cards) HiCo write capability available Ordering Information Magnetic Tracks Supported (R, R/W) 12 3 Center JIS II IC Contact Interface Shutter Cover Cable Color Part Number R/W R/W R/W Option TTL Option No No Black 3S4YR-MKW1PC-01 R/W R/W R/W Option TTL Option No No Black 3S4YR-MKW1PCH R/W Option TTL Option No No Black 3S4YR-MKW4PC-01 R/W R/W R/W R/W TTL No lnlet No No Black 3S4YR-MKWAPC-100k Note: Only the MKW1PCH is capable of writing HiCo cards. All models can read HiCo cards.3S4YR-MKW 3S4YR-MKW TYPICAL APPLICATIONS Cash Dispensers ID Card Checkers Automatic Teller Machines (ATM) Electronic Lock Systems POS Terminals Medical Patient Systems Credit Card Checkers Health Control Systems ACCESSORIES Description Part Number (See note 1) IC Contact, chip on the front, lower position IC CONTACT J (See note 1) IC Contact, chip on the front, upper and lower positions IC CONTACT X Shutter for MKW1PC-01, MKW1PCH SHUTTER MKD7 Shutter for MKW4PC-01 SHUTTER MKD4 Note 1: Consult your Omron sales representative for IC contact accessories. Special configurations can be supplied. Specifications Part number 3S4YR-MKW Recommended card type Magnetic card ISO 7810-7813 IC card ISO 7816/1, 2 Recording method FM decoding (F2F) Card feeding speed 20 cm/sec 10% (7.87 in/sec) Motor type DC motor Service life (See note) 1,200,000 passes min. Operating power supply Amplifier 24 VDC 10% Motor 24 VDC 10% Control logic 5 VDC 5% Current consumption Amplifier 260 mA max. Motor 1.7 A max. Control logic 330 mA max. Mounting location Anywhere not directly subject to water or rain Mounting orientation Stripe top or stripe bottom Ambient temperature Operation -5 to 55C (23 to 131F) Storage -25 to 70C (-13 to 158F) Ambient humidity Operation 45% to 85% RH without condensation Storage 30% to 90% RH Vibration 10 to 55 Hz, 2 mm double amplitude, for 30 minutes in X, Y, and Z directions 2 Shock 300 m/sec (30 G) in each of X, Y, and Z directions Dimensions With shutter 247L x 106W x 92H mm (9.72L x 4.17W x 3.62H in) Without shutter 222L x 98W x 92H mm (8.74L x 3.86W x 3.62H in) Weight Approx. 1.9 kg (4.2 lbs) when fully equipped Note: One pass denotes one round trip.
