PART NUMBER :R284C0351053
TECHNICAL DATA SHEET
Issue : NA
CABLE ASSEMBLY
Date : NA
No.390, Yong He Road,
Shanghai 200072, China
Customer : Radio Spares Specification : NA Issue : NA Date : N/A
All dimensions are in mm
Connectors designation : Connector 1 : SMA Straight Plug Crimp Type Connector 2 : SMA Straight Plug Crimp Type
Cable 2.6/50 S (R124.071.120) Cable 2.6/50 S (R124.071.120)
Cable designation : Flexible Cable 2.6/50S (RG316)
C291.170.007
Nominal length : Lg: 500 mm
Cable colour : Brown
2.49 mm
Outer diameter :
HearShrink Sleeves (9.11.95.000.70)
Accessories :
ELECTRICAL CHARACTERISTICS :
High Frequency Low Frequency
Insulation Resistance : 5000 MOhms min
Characteristic impedance : 502 Ohms
Voltage Rating : 250 Veff max
Frequency range : DC-3GHz
Insertion Loss : 0.97 dB max @ 3GHz & 20C
VSWR. : TBT
MECANICAL CHARACTERISTICS :
Recommend min. bend radius : 10 mm
Cable crush resistance : NA
Life ( connectors) : 100 cycles
ENVIRONMENTAL CHARACTERISTICS :
CUSTOMER'S APPROVAL
Operating temperature range : -55C to +135C
Service or
Remark : NA
Company's stamp
Attachment : R124.071.120-TDS
Name
C291.170.007 (RG316)-TDS
Date
Cable Assembly is RoHS compliant.
Peter A 2007-5-25 Creation Willy
Name Issue Date Modification Checked by
PART NUMBER :R284C0351054
TECHNICAL DATA SHEET
Issue : NA
CABLE ASSEMBLY
Date : NA
No.390, Yong He Road,
Shanghai 200072, China
Customer : Radio Spares Specification : NA Issue : NA Date : N/A
All dimensions are in mm
100020mm
R124.071.120
R124.071.120
C291.170.007
RADIALL
R284C0351054
-- --
9.11.95.000.70
302mm
Year Month
9.11.95.000.70
302mm
4875mm
501.14.040A
Connectors designation : Connector 1 : SMA Straight Plug Crimp Type Connector 2 : SMA Straight Plug Crimp Type
Cable 2.6/50 S (R124.071.120) Cable 2.6/50 S (R124.071.120)
Cable designation : Flexible Cable 2.6/50S (RG316)
C291.170.007
Nominal length : Lg: 1000 mm
Cable colour : Brown
2.49 mm
Outer diameter :
HearShrink Sleeves (9.11.95.000.70)
Accessories :
ELECTRICAL CHARACTERISTICS :
High Frequency Low Frequency
Insulation Resistance : 5000 MOhms min
Characteristic impedance : 502 Ohms
Voltage Rating : 250 Veff max
Frequency range : DC-3GHz
Insertion Loss : 1.81 dB max @ 3GHz & 20C
VSWR. : TBT
MECANICAL CHARACTERISTICS :
Recommend min. bend radius : 10 mm
Cable crush resistance : NA
Life ( connectors) : 100 cycles
ENVIRONMENTAL CHARACTERISTICS :
CUSTOMER'S APPROVAL
Operating temperature range : -55C to +135C
Service or
Remark : NA
Company's stamp
Attachment : R124.071.120-TDS
Name
C291.170.007 (RG316)-TDS
Date
Cable Assembly is RoHS compliant.
Peter A 2007-5-25 Creation Willy
Name Issue Date Modification Checked by
