EMI9404MUTAG ON Semiconductor

EMI9404 PRAETORIAN III 4-Channel EMI Array with ESD Protection Description EMI9404 Figure 1. Electrical Schematic Table 1. PIN DESCRIPTIONS Pin Name Description 1 FILTER1 Filter + ESD Channel 1 (Internal) 2 FILTER2 Filter + ESD Channel 2 (Internal) 3 FILTER3 Filter + ESD Channel 3 (Internal) 4 FILTER4 Filter + ESD Channel 4 (Internal) 5 FILTER4 Filter + ESD Channel 4 (External) 6 FILTER3 Filter + ESD Channel 3 (External) 7 FILTER2 Filter + ESD Channel 2 (External) 8 FILTER1 Filter + ESD Channel 1 (External) GND PAD GND Device Ground SPECIFICATIONS MAXIMUM RATINGS Parameter Value Unit Storage Temperature Range 65 to +150 C Current per Inductor 15 mA DC Package Power Rating 500 mW Stresses exceeding Maximum Ratings may damage the device. Maximum Ratings are stress ratings only. Functional operation above the Recommended Operating Conditions is not implied. Extended exposure to stresses above the Recommended Operating Conditions may affect device reliability. STANDARD OPERATING CONDITIONS Parameter Rating Unit Operating Temperature Range 40 to +85 C
