2330 Abbatron

ALL NEW PRODUCTS S t a y C o n n e c t e d w i t h H E Y w a r e Heyco PVC and Nylon LED Spacers Fits T-1 (3 mm) Fits T-1 3/4 (5 mm) Fits T-1 (3 mm) Fits T-1 3/4 (5 mm) HLEDS2 HLEDS3 HLEDS1E HLEDS2E A PART NO. DESCRIPTION PART NO. DESCRIPTION PART NO. DESCRIPTION PART NO. DESCRIPTION in. mm. Black PVC* Black PVC Natural Natural .187 4,8 11025 HLEDS3-03 11032 HLEDS1E-03 11041 HLEDS2E-03 .250 6,4 11019 HLEDS2-04 11026 HLEDS3-04 11033 HLEDS1E-04 11042 HLEDS2E-04 .375 9,5 11020 HLEDS2-06 11027 HLEDS3-06 11034 HLEDS1E-06 11043 HLEDS2E-06 .500 12,7 11021 HLEDS2-08 11028 HLEDS3-08 11035 HLEDS1E-08 11044 HLEDS2E-08 .625 15,9 11022 HLEDS2-10 11029 HLEDS3-10 11036 HLEDS1E-10 11045 HLEDS2E-10 .750 19,1 11023 HLEDS2-12 11030 HLEDS3-12 11037 HLEDS1E-12 11046 HLEDS2E-12 .875 22,2 11038 HLEDS1E-14 11047 HLEDS2E-14 1.000 25,4 11039 HLEDS1E-16 11048 HLEDS2E-16 Standard as color noted. *V-0 material available, consult Heyco. For Heyco PCB Surface Mount Miniature Connectors for LED PCBs, contact Heyco. Heyco Transistor Insulators PART NO. DESCRIPTION PART NO. DESCRIPTION PART NO. DESCRIPTION Black Black Black 12015 IEC-220-18 GF 12016 IEC-220V-18 GF 12017 IEC-218-18 GF HLEDS2 HLEDS3 HLEDS1E & HLEDS2E Transistor Insulators Material PVC PVC Nylon 6/6 Nylon Glass-filled 6/6 Flammability Rating 94HB 94HB 94V-2 94HB Temperature Range 32F (0C) to 185F (85C) (All) see HLEDS2 see HLEDS2 -22F (-30C) to 284F (140C) 1-800-526-4182 732-286-1800 (NJ) FAX: 732-244-8843 www.heyco.com 7-33
