AMES75-051212TNZ Aimtec

Name: AMES75-051212TNZ
Brand: Aimtec
SKU: AMES75051212TNZ_Aimtec
Availability: OutOfStock
Rating: 5 (11 reviews)

AMES75-051212TNZ electronic component of Aimtec

Images are for reference only, See Product Specifications

X-On Electronics has gained recognition as a prominent supplier of AMES75-051212TNZ AC/DC Power Modules across the USA, India, Europe, Australia, and various other global locations. AMES75-051212TNZ AC/DC Power Modules are a product manufactured by Aimtec. We provide cost-effective solutions for AC/DC Power Modules, ensuring timely deliveries around the world.

Part No.	AMES75-051212TNZ
Manufacturer:	Aimtec
Category:	AC/DC Power Modules
Description:	Power supply: switched-mode; 69.6W; 85÷264VAC; Usup: 120÷373VDC
Datasheet:	AMES75-051212TNZ Datasheet (PDF)

Price (USD)

1: USD 63.8453 ea
Line Total: USD 63.85

Availability : 0

Qty	Unit Price
1	$ 63.8453
2	$ 60.4188

AMES75-051212TNZ More Buying Options & Price Grid(s)

Availability

Price (USD)

Quantity

Availability 0

Ship by Mon. 25 Aug to Fri. 29 Aug

MOQ : 1
Multiples : 1

Qty	Unit Price
1	$ 67.6573
5	$ 64.2388

Availability 0

Ship by Thu. 21 Aug to Mon. 25 Aug

MOQ : 1
Multiples : 1

Qty	Unit Price
1	$ 63.8453
2	$ 60.4188

Specifications

Manufacturer Aimtec Aimtec
Product Category AC/DC Power Modules AC/DC Power Modules
Number of Outputs 3 3
Category AC/DC Power Modules AC/DC Power Modules
Electrical Connection screw terminals screw terminals
Weight 310 g 310 g
Output Current 6 A 6 A
Type Of Power Supply impulse impulse
Output Voltage 5 VDC 5 VDC
Protection short circuit protection SCP, anti - overload OPP, anti - overvoltage OVP short circuit protection SCP, anti - overload OPP, anti - overvoltage OVP
Supply Voltage 85 To 264 VAC , 120 To 373 VDC 85 To 264 VAC , 120 To 373 VDC
Mounting for building in for building in
Power Supply/Converter Features r A ted p A r A meters obt A ined @ full lo A d r A ted p A r A meters obt A ined @ full lo A d
Output Voltage 2 12 VDC 12 VDC
Output Current 2 2.8 A 2.8 A
Kind Of Power Supply V olt A ge source V olt A ge source
Output Current 3 500 mA 500 mA
Output Voltage 3 - 12 VDC - 12 VDC
Kind Of Case AMES AMES
Body Dimensions 129x97x30mm 129x97x30mm
Operating Temperature - 30 To 70 C - 30 To 70 C
Efficiency 82 % 82 %
Manufacturer Series AMES75 - NZ AMES75 - NZ
Power 69.6 W 69.6 W

We are delighted to provide the AMES75-051212TNZ from our AC/DC Power Modules category, at competitive rates not only in the United States, Australia, and India, but also across Europe and beyond. A long established and extensive electronic component distribution network has enhanced our global reach and dependability, ensuring cost savings through prompt deliveries worldwide. Client satisfaction is at the heart of our business, where every component counts and every customer matters. Our technical service team is ready to assist you. From product selection to after-sales support, we strive to deliver a seamless and satisfying experience. Are you ready to experience the best in electronic component distribution? Contact X-ON Electronics today and discover why X-On are a preferred choice for the AMES75-051212TNZ and other electronic components in the AC/DC Power Modules category and beyond.
