Alpha Wire 711 Lidgerwood Avenue, Elizabeth, NJ 07207 Tel: 1-800-52 ALPHA (25742), Web: www.alphawire.com Customer Specification PART NO. 76020 Construction Diameters (In) 1) Component 1 4 X 1 PAIR a) Conductor 24 (7/32) AWG BC 0.024 0.008 Wall, Nom. Polypropylene b) Insulation 0.039 (PP) (1) Color(s) Pair Color Pair Color Pair Color 1 BLU - WHT/BLU 2 ORG - WHT/ORG 3 GRN-WHT/GRN 4 BRN - WHT/BRN c) Pair 2/Cond Cabled Together (1) Lay Length: Various Lay 2) Cable Assembly 4 Components Bunch Cabled a) Twists: 2.4Twists/foot 3) Jacket 0.035 Wall, Nom.,TPE 0.247 Avg.(0.255 Max.) a) Color(s) BLACK, RED b) Ripcord Nylon ALPHA WIRE-* P/N 76020 4PR 24 AWG XTRAGUARD(R) INDUSTRIAL ETHERNET (UL) C(UL) TYPE c) Print CMR 75C FT4 ANSI/TIA-568-C.2 CAT5E VERIFIED CE ROHS (SEQUENTIAL FOOTAGE MARKING) * = Factory Code Applicable Specifications 1) UL CMR 75C FT4 2) CSA International C(UL) TYPE CMR 75CFT4 3) CE: EU Low Voltage Directive 2014/35/EU Environmental 1) CE: EU Directive 2011/65/EU(RoHS2): This product complies with European Directive 2011/65/EU (RoHS Directive) of the European Parliament and of the Council of 8 June 2011. No Exemptions are required for RoHS Compliance on this item. Consult Alpha Wire s web site for RoHS C of C. 2) REACH Regulation (EC 1907/2006): This product does not contain Substances of Very High Concern (SVHC) listed on the European Union s REACH candidate list in excess of 0.1% mass of the item. For up-to-date information, please see Alpha s REACH SVHC Declaration. Properties Physical & Mechanical Properties 1) Temperature Range -50 to 75C 2) Bend Radius 4X Cable Diameter 3) Pull Tension 28.0 Lbs, Maximum 4) Sunlight Resistance Yes Electrical Properties (For Engineering purposes only) 300 V 1) Voltage Rating RMS 2) Characteristic Impedance 100 +/- 15 3) Mutual Capacitance 5.6 nf/100m Max 4) Velocity of Propagation 70 % Nom. 5) Conductor DCR 9.38 /100m 20C, Max 6) Skew 45 ns/100m, Max 7) Pair to Ground Unbalance 330 pf/100m, Max 8) DC Unbalance of a Pair 5%, Max 9) Insertion Loss, Max dB/100m 2.4 1 MHz 4.9 4 MHz 6.9 8 MHz 7.8 10 MHz 9.9 16 MHz
