CYG4/3 Altech

CY SERIES GROUND / EARTH TERMINAL BLOCKS SCREW TERMINAL BLOCKS CYG2.5 CYG4 CYG6 HIGHLIGHTS FEATURES 2 connection grounding terminals Yellow/ Green Color as per Industry standard 2 Connection Ground Terminal 2 Connection Ground Terminal 2 Connection Ground Terminal Snap-on feet 2 Jumper Channels 2 Jumper Channels 2 Jumper Channels Dimensions & Weight Width 5 mm 6 mm 8 mm APPLICATIONS Length 50 mm 50 mm 50 mm Grounding Applications 49 mm 49 mm 49 mm Height w DIN Rail 35 x 7.5 mm 35 x 15 mm 56.5 mm 56.5 mm 56.5 mm Weight per piece 11.7 g 13.7 g 22.9 g Technical Data/Ratings Approvals E220514 60947-7-1 E220514 60947-7-1 E220514 60947-7-1 2 2 2 24-12 AWG 0.2-2.5 mm 24-10 AWG 0.2-4 mm 24-8 AWG 0.2-6 mm Wire Size (solid stranded) Voltage Rating 600 V 1000V AC/DC 600 V 1000V AC/DC 600 V 1000V AC/DC Current Rating Torque 3.6 lb.in 0.4 Nm 4.5 lb.in 0.8 Nm 11 lb.in 1.2 Nm Insulation Material Polyamide 66 Polyamide 66 Polyamide 66 Installation Instructions Wire Stripping Length 8 mm 9 mm 10 mm Screwdriver Flat Head 0.5 x 3 mm Flat Head 0.6 x 3.5 mm Flat Head 0.8 x 4 mm Terminal Blocks Cat. No. Std. Pk. Cat. No. Std. Pk. Cat. No. Std. Pk. Yellow / Green CYG2.5 100 CYG4 100 CYG6 100 Accessories Cat. No. Std. Pk. Cat. No. Std. Pk. Cat. No. Std. Pk. EPCY2.5/10 50 EPCY2.5/10 50 EPCY2.5/10 50 End Plate Partition Plate PPCY2.5/10 20 PPCY2.5/10 20 PPCY2.5/10 20 DIN Rail 2511120 50 2511120 50 2511120 50 CA701-15/S 50 CA701-15/S 50 CA701-15/S 50 End Stop CA702 50 CA702 50 CA702 50 CA802 50 CA802 50 CA802 50 CA103 50 CA103 50 CA103 50 Shorting Link/ 2 pole JX2.5/2 100 JX4/2 100 JY6/2 100 Jumpers 3 pole JX2.5/3 50 JX4/3 50 4 pole JX2.5/4 50 JX4/4 50 5 pole JX2.5/5 50 6 pole JX2.5/6 50 7 pole JX2.5/7 10 8 pole JX2.5/8 10 JX4/8 10 10 pole JX2.5/10 10 JX4/10 10 16 pole JX4/16 10 MT5 1 Pk. (100 tags) MT6 1 Pk. (100 tags) MT8 1 Pk. (100 tags) Marking Tag WLX2.5 100 WLX4 100 WLX6 100 Warning Label 8 Altech Corp. 35 Royal Road Flemington, NJ 08822-6000 Phone (908)806-9400 FAX (908)806-9490X-ON Electronics Largest Supplier of Electrical and Electronic Components Click to view similar products for DIN Rail Terminal Blocks category: Click to view products by Altech manufacturer: Other Similar products are found below : 00110420202 8WA1011-1BH23 8WA1011-1EF20 91.010 9102100000 91.040 9123140000 9123140001 1333564 DP25-GY-ND 1431306 1433306 90.070 91.020 912314 260-301 NR 280-331 280-560 280-564 281-611/281-542 281-673/281-411 281-994 283-317 283-607 284-691 2909798 264-724 264-726 280-530 280-555 280-619 281-610 281-622/281-417 284-317 284-601 2907033 35956 USK 10 102510 1025100000 5520682 591620-2 1-591651-1 8671050000 264-706 280-575 592814-1 592814-3 UMSTBVK 2 5/ 5-STF-5 08 NRA37-12
