CLF1G0035-50HU Ampleon

CLF1G0035-50 CLF1G0035S-50 Broadband RF power GaN HEMT Rev. 6 8 January 2016 Product data sheet 1. Product profile 1.1 General description CLF1G0035-50 and CLF1G0035S-50 are broadband general purpose 50 W amplifiers with first generation GaN HEMT technology from Ampleon. Frequency of operation is from DC to 3.5 GHz. Table 1. CW and pulsed RF application information Typical RF performance at T = 25 C I = 150 mA V = 50 V in a class-AB broadband demo case Dq DS board. Test signal f P G L p D (MHz) (W) (dB) (%) 1-Tone CW 500 50 12 64 1000 50 13 43 1500 50 13 43 2000 50 14 43 2500 50 11 48 1 1-Tone pulsed 500 50 12 65 1000 50 15 43 1500 50 15 43 2000 50 15 44 2500 50 13 49 1 Pulsed RF t = 100 s =10 %. p Table 2. 2-Tone CW application information Typical 2-Tone performance at T = 25 C I = 275 mA V = 50 V in a class-AB broadband case Dq DS demo board. Test signal f P IMD3 L(PEP) (MHz) (W) (dBc) 1 2-Tone CW 500 10 48 1000 10 40 1500 10 43 2000 10 38 2500 10 38 1 2-Tone CW f=1MHz.CLF1G0035-50 CLF1G0035S-50 Broadband RF power GaN HEMT 1.2 Features and benefits Frequency of operation is from DC to 3.5 GHz 50 W general purpose broadband RF Power GaN HEMT Excellent ruggedness (VSWR 10 : 1) High voltage operation (50 V) Thermally enhanced package 1.3 Applications Commercial wireless infrastructure (cellular, WiMAX) Industrial, scientific, medical Radar Jammers Broadband general purpose amplifier EMC testing Public mobile radios Defense application 2. Pinning information Table 3. Pinning Pin Description Simplified outline Graphic symbol CLF1G0035-50 (SOT467C) 1drain 1 1 2gate 2 1 3source 3 3 2 aaa-003693 CLF1G0035S-50 (SOT467B) 1drain 1 1 2gate 2 1 3source 3 3 2 aaa-003693 1 Connected to flange. 3. Ordering information Table 4. Ordering information Type number Package Name Description Version CLF1G0035-50 - flanged ceramic package 2 mounting holes 2 leads SOT467C CLF1G0035S-50 - earless ceramic package 2 leads SOT467B CLF1G0035-50 1G0035S-50 All information provided in this document is subject to legal disclaimers. Ampleon Netherlands B.V. 2016. All rights reserved. Product data sheet Rev. 6 8 January 2016 2 of 19
