Data Sheet High Power Programmable DC Power Supplies PVS Series Features & Benefits Compact, high power density, 2U package Output up to 1000 V / 5 A (PVS10005) and 600 V / 8.5 A (PVS60085 & PVS60085MR) Convenient single-phase AC input configuration Bright VFD display High voltage and current resolution of 0.1 V, The PVS10005, PVS60085, and PVS60085MR programming time and increase productivity. The 0.1 mA (PVS10005) or 10 mV, 0.2 mA programmable DC power supplies offer clean application software allows users to control the (PVS60085 & PVS60085MR) output power up to 5.1 kW, excellent regulation, power supply, execute test sequences, or log Fast transient response time of 0.5 ms and fast transient response time characteristics in measurements. It also integrates with Data Adjustable voltage and current slope (rise and an industry leading 2U package. Dashboard for LabVIEW apps, enabling users to fall times) remotely monitor select measurement indicators List mode: 9 user-defined programs with up to These power supplies provide many useful with iOS, Android, or Windows 8 compatible 100 programmable steps each features such as high programming resolution, tablets or smart phones. Built-in SAS function for storage of up to 16 multiple remote interfaces for test systems, and a I-V curves with Voc, Isc, Vmp, and Imp built-in SAS (solar array simulator) function to These power supplies are well suited for both parameters and 1024-point table generate PV (photovoltaic) I-V curves. The bench use and ATE systems integration, R&D, Store up to 100 different instrument settings optional SAS software allows users to consistently design verification, production test, and high to internal memory reproduce various I-V curves to test a PV voltage testing. Control up to 30 power supplies from one PC inverters MPPT efficiency. via the RS485 interface Timer-controlled output (1 s to 1000 hrs) For benchtop applications, this series provides an Special Applications Standard USB (virtual COM), RS232, RS485, intuitive user interface with full keypad and rotary GPIB and LAN interfaces In particular, the low-noise characteristic of the knob. System integrators benefit from the standard External analog programming and monitoring PVS Series makes these instruments ideal for USB (virtual COM), RS232, GPIB, and LAN interface motor inverter testing. When operated with the interfaces supporting SCPI commands. Free Extensive protection features: OVP, OCP, OPP, optional SAS software, these power supplies application software and a complete set of OTP, foldback protection mode, and key-lock can be used for solar array testing applications LabVIEW drivers are available to reduce function such as validating a solar inverters MPPT Front to rear airflow allows for efficient cooling algorithm and testing to EN50530 and Sandia in high rack density environments Labs standards. Master/slave mode for parallel operation LabVIEW driver and softpanel for remote control, test sequence generation, and Model PVS10005 PVS60085 PVS60085MR** datalogging available Max Output Voltage 1000 V 600 V 600 V Max Output Current 5 A 8.5 A 8.5 A Max Output Power 5000 W 5100 W 3000 W **Model PVS60085MR is a multi-ranging supply allowing any combination of the rated voltage and current up to the maximum output power of 3000 W. Technical data subject to change www.bkprecision.com B&K Precision Corp. 2018High Power Programmable DC Power Supplies PVS Series Front panel Bright VFD display Protection LED indicators Function keys Numeric keypad Rotary knob Cursor keys Intuitive user interface The numeric keys and rotary knob provide a convenient interface for setting output levels quickly and precisely. Both measured output values and setting values are concurrently displayed on the screen. Additionally, the power supplies provide internal memory for storage of up to 10 different instrument settings that can be set and recalled via both the front panel and remote interfaces. Rear panel RS-232 interface LAN interface GPIB interface Ground chassis Output and USB interface RS-485 External analog Single-phase AC line input remote sense interface control interface Unlike other 5 kW power supplies that need a terminal 3-phase mains connection, this series only requires a single-phase connection, which is easier to wire and much more commonly available than 3-phase AC outlets. 2 www.bkprecision.com
