ES-UA-5A and ES-VA-5A E-Stop Safety Modules Model ES-UA-5A for 12-24V dc/115 ac operation model ES-VA-5A for 12-24V dc/230 ac operation Original Instructions Monitors emergency stop devices, such as palm buttons and rope/cable pulls, and positive-opening safety switches used for guard/gate inter- locking The safety inputs can monitor: Hard/relay contacts in a dual-channel hookup using terminals S11- S12 and S21-S22, or A +24V dc source switched by hard/relay contacts in single-channel hookup Four normally open output switching channels for connection to control- reliable power interrupt circuits and three auxiliary output channels Automatic reset or monitored manual reset Design complies with standards ANSI B11.19, UL991, ISO 13850 (EN418), and ISO 13849-1 (EN954-1) (Safety Category 4) For use in functional stop category 0 applications per ANSI NFPA 79 and IEC/EN60204-1 6 amp safety output contacts 5 amp aux. output contacts Plug-in terminal blocks Models Supply Voltage Outputs Output Rating ES-UA-5A 12-24V dc or 115V ac 4 Normally open safety N.O. Safety Outputs: 6 A 1 Normally closed aux. N.C. Aux. Outputs: 5 A ES-VA-5A 12-24V dc or 230V ac 2 Solid-state aux. SS Aux. Outputs: 100 mA WARNING: Not a Stand-Alone Safeguarding Device This Banner device is not a stand-alone point-of-operation guarding device, as defined by OSHA regulations. It is necessary to install point-of-operation guarding devices, such as safety light screens and/or hard guards, to protect personnel from hazardous machinery. Failure to install point-of-operation guards on hazardous machinery can result in a dangerous condition which could lead to serious injury or death. Important: Read This First The user is responsible for satisfying all local, state, and national laws, rules, codes, and regulations relating to the use of this product and its application. Banner Engineering Corp. has made every effort to provide complete application, installation, operation, and maintenance instructions. Please direct any questions regarding the use or installation of this product to the factory applications depart- ment at the telephone numbers or address found at ES-UA-5A and ES-VA-5A E-Stop Safety Modules ANSI B11.19 Performance Criteria for Safeguarding Contact: Safety Director, AMT The Association for Manufacturing Technology, 7901 Westpark Drive, McLean, VA 22102, Tel.: 703-893-2900 ANSI NFPA 79 Electrical Standard for Industrial Machinery Contact: National Fire Protection Association, 1 Batterymarch Park, P.O. Box 9101, Quincy, MA 02269-9101, Tel.: 800-344-3555 ANSI/RIA R15.06 Safety Requirements for Industrial Robots and Robot Systems Contact: Robotic Industries Association, 900 Victors Way, P.O. Box 3724, Ann Arbor, MI 48106, Tel.: 734-994-6088 Applicable International Standards ISO 12100-1 & -2 (EN 292-1 & -2) Safety of Machinery Basic Concepts, General Principles for Design IEC 60204-1 Electrical Equipment of Machines Part 1: General Requirements IEC 61508 Functional Safety of Electrical/Electronic/Programmable Electronic Safety-Related Systems IEC 62061 Functional Safety of Safety-Related Electrical, Electronic and Programmable Control Systems ISO 13849-1 (EN 954-1) Safety-Related Parts of Control Systems ISO 13850 (EN 418) Emergency Stop Devices, Functional Aspects Principles for Design Contact: Global Engineering Documents, 15 Inverness Way East, Englewood, CO 80112-5704, Tel.: 800-854- 7179 Overview An Emergency Stop Safety Module is used to increase the control re- liability of an emergency stop circuit. As shown in the hookup draw- S31 S32 S33 S34 S32 S35 ings, the models ES-UA-5A and ES-VA-5A E-Stop Safety Modules (the Safety Modules) are designed to monitor a 1-channel or 2-chan- A1 A2 B1 B2 S11 S12 S21 S22 nel E-stop switch. A 2-channel E-stop switch has two electrically iso- lated contacts. 13 14 23 24 33 34 43 44 Y30 Y31 Y32 Y35 51 52 Figure 1. Features and Terminals Safety Circuit Integrity and ISO 13849-1 (EN954-1) Safety Circuit Principles Safety circuits involve the safety-related functions of a machine that minimize the level of risk of harm. These safety-related functions can prevent initiation, or stop or remove a hazard. A failure of a safety-related function or its associated safety circuit may result in an in- creased risk of harm. The integrity of a safety circuit depends on several factors, including fault tolerance, risk reduction, reliable and well-tried components, well-tried safety principles, and other design considerations. Depending on the level of risk associated with the machine or its operation, an appropriate level of safety circuit performance must be incorporated. ANSI/RIA R15.06 Industrial Robots, ANSI B11 Machine Tools, OSHA 29CFR1910.217 Mechanical Power Presses, and ISO 13849-1 (EN954-1) Safety-Related Parts of a Control System standards provide details of the safety performance levels. Safety Circuit Integrity Levels The safety circuits in International and European standards have been segmented into categories, depending on their ability to maintain their integrity in the event of a failure. The most recognized standard that details safety circuit integrity levels is ISO 13849-1 (EN954-1), which establishes five levels: Categories B, 1, 2, 3, and 4 (most strict). 2 www.bannerengineering.com - tel: 763-544-3164 P/N 122365 Rev. E
