3360Y-1-204LF Bourns

3360 Y 503 Features n RoHS compliant* version available n Conductive plastic n Linear tapers n Audio tapers available n PC board and bushing mount n Plastic bushing and plastic shaft n Withstands typical industrial washing processes 3360 - 6 mm Square Sealed Panel Control Electrical Characteristics Physical Characteristics Standard Resistance Table Standard Resistance Range Stop Strength......... 5.65 N-cm (8 oz.-in.) Resistance Resistance Linear ..............1K ohms to 1 megohm Mechanical Angle .............310 nominal (Ohms) Code Total Resistance Tolerance Torque 1,000 102 2,000 202 Linear Tapers ............................20 % Starting 5,000 502 Independent Linearity .....................5 % ........3.53 N-cm (5.0 oz.-in.) maximum 10,000 103 Absolute Minimum Resistance Running 20,000 203 ............................2 % or 2 ohms max.......3.53 N-cm (5.0 oz.-in.) maximum 50,000 503 ......................... (whichever is greater) Mounting (Torque on Bushing) 100,000 104 Effective Electrical Angle ..240 nominal ............17 N-cm (1.5 lb.-in.) maximum 200,000 204 Contact Resistance Variation plastic bushing 500,000 504 ............................1 % or 3 ohms max. Weight ...................................4.5 grams 1,000,000 105 (whichever is greater) Terminals ....................... Solderable pins Dielectric Withstanding Voltage Soldering Condition Popular distribution resistance values listed in boldface. Special resistances available. (MIL-STD-202 Method 301) ..........5 seconds at 260 C maximum. Sea Level .............. 900 VAC minimum Recommended hand soldering 70,000 Feet ........... 350 VAC minimum using Sn95/Ag5 no clean solder, How To Order Insulation Resistance 0.025 wire diameter. 3360 Y - 1 - 103 LF .................. 1,000 megohms minimum Marking .........Manufacturers trademark, Model Power Rating 70 C model number, product code, (Derate to 0 at 125 C terminal style, resistance code Terminal Style Designator Voltage Limited By Power Dissipation and date code Single Cup: or 200 VAC, Whichever is Less) Flammability ........ Conforms to UL94V-0 C = In-line Straight Terminals Side Exit ............................................25 watts Epoxy................... Conforms to UL94V-1 P = 5.08 mm x 2.54 mm Audio Tapers .................... 0.125 watts Hardware (purchased separately) Triangular Pattern Theoretical Resolution Nut ............................................H-38-1 Rear Exit ............................... Essentially infinite Washer .....................................H-37-5 Y = 5.08 mm x 5.08 mm MSL ......................................................1 Triangular Pattern Environmental Characteristics ESD Classification (HBM) .....................2 Rear Exit Operating Temperature Range Bushing Designator .................................+1 C to +125 C 1 = Standard Storage Temperature Range Resistance Code ................................-55 C to +125 C Temperature Coefficient Terminations Over Storage Temperature Range LF = 100 % Tin-plated (RoHS compliant) Blank = 90 % Tin / 10 % Lead-plated ................................... 1,000 ppm/C (Standard) Vibration ......................................... 30 G Total Resistance Shift .... 2 % maximum Voltage Ratio Shift..... 2 % maximum Shock............................................ 100 G Total Resistance Shift ...2 % maximum Voltage Ratio Shift...... 2 % maximum Load Life ............................. 1,000 Hours Total Resistance Shift .........................10 % TRS maximum Rotational Life (No Load) .. 50,000 Cycles Total Resistance Shift ...........................5 % TRS maximum Contact Resistance Variation ....................................3 % or 3 ohms, whichever is greater Moisture Resistance ........ MIL-STD-202, Method 103, Condition B Total Resistance Shift .........................10 % TRS maximum IP Rating .........................................IP 67 WARNING Cancer and Reproductive Harm - www.P65Warnings.ca.gov *RoHS Directive 2015/863, Mar 31, 2015 and Annex. Specifications are subject to change without notice. Users should verify actual device performance in their specific applications. The products described herein and this document are subject to specific legal disclaimers as set forth on the last page of this document, and at www.bourns.com/docs/legal/disclaimer.pdf. 247C0 3360 - 6 mm Square Sealed Panel Control Product Dimensions COMMON DIMENSIONS 3360C 6.35 .025 1/4-32 UNEF-2A (.250 .010) THREADED PLASTIC MOUNTING DIA. BUSHING 3.35 .33 2.36 .050 6.71 .25 5.59 .25 DIA. (.131) (.093 .002) (.013) (.264 .010) (.220 .010) MIN. ACROSS FLATS STANDOFF 6.78 .25 3.20 .25 (.266 .010) (.126 .010) 5.44 5.97 .89 .38 (.214) (.235 .035) (.015) MIN. MIN. FULL STANDOFF THREAD 6.35 3.91 .38 3 2 1 2.54 .25 2.54 .25 (.250) (.154 .015) (.100 .010) (.100 .010) 12.70 .64 4.70 .38 .46 .05 (.185 .015) (.500 .025) DIA. (.018 .002) ADJUSTMENT SLOT SOLDER PLATED .64 .10 .76 .25 COPPER PINS WIDE X DEEP (.025 .004) (.030 .010) 3360P 5.97 .89 (.235 .035) .33 (.013) MIN. STANDOFF 2.54 .38 2 (.100 .015) 3 1 3.58 .38 2.54 .25 2.54 .25 (.141 .015) (.100 .010) (.100 .010) TYP. 3360Y 5.97 .89 (.235 .035) 5.08 .25 2 (.200 .010) 3 1 .97 .38 2.54 .25 2.54 .25 (.038 .015) (.100 .010) (.100 .010) 2 WIPER MM CCW CW DIMENSIONS: 1 3 (INCHES) CLOCKWISE REV. 10/19 Specifications are subject to change without notice. Users should verify actual device performance in their specific applications. The products described herein and this document are subject to specific legal disclaimers as set forth on the last page of this document, and at www.bourns.com/docs/legal/disclaimer.pdf.
