SRN6045-1R3Y Bourns

8R2 Features Applications n Semi-shielded construction n DC/DC converters n High rated current n Notebook computers n Component height 4.5 mm n Digital video cameras n Inductance range: 1 to 220 H n HDDs n Rated current up to 4.2 A n Cell phones n RoHS compliant* and halogen free** n Televisions, LCD displays SRN6045 Series - Semi-shielded Power Inductors Electrical Specifications 25 C General Specifications Operating Temperature Inductance 6.0 0.2 Test SRF DCR ................................. -40 C to +125 C 100 KHz/1 V (.236 .008) Q Freq. (MHz) (W) Irms Isat (Temperature rise included) Bourns Part No. L (mH) Tol. % (Ref.) (MHz) Typ. Max. (A) (A) Storage Temperature (Component) SRN6045-1R0Y 1.0 30 15 7.96 50 0.0139 4.2 8.5 ................................. -40 C to +125 C SRN6045-1R3Y 1.3 30 15 7.96 48 0.017 4.0 8.0 Resistance to Solder Heat 6.0 0.2 ...............................+250 C for 10 sec. SRN6045-1R8Y 1.8 30 15 7.96 38 0.0198 3.7 7.0 (.236 .008) Temperature Rise .....40 C at rated Irms SRN6045-2R2Y 2.2 30 15 7.96 35 0.0251 3.5 6.0 Rated Current SRN6045-3R3Y 3.3 30 15 7.96 27 0.0302 3.2 5.0 ............ Inductance drops 30 % at Isat SRN6045-4R7Y 4.7 30 15 7.96 22 0.0376 3.0 4.0 Moisture Sensitivity Level .....................1 ESD Classification (HBM) ................. N/A SRN6045-6R8Y 6.8 30 15 7.96 20 0.0473 2.8 3.8 SRN6045-8R2Y 8.2 30 15 7.96 18 0.055 2.7 3.3 Materials SRN6045-100M 10 20 17 2.52 15 0.0586 2.5 3.0 SRN6045-150M 15 20 17 2.52 13 0.0958 1.9 2.3 Core ..............................................Ferrite 4.5 Wire ............................Enameled copper SRN6045-220M 22 20 17 2.52 11 0.142 1.5 1.9MAX. 2.5 (.177) REF. Terminal Finish ........................Sn/Ag/Cu (.098) SRN6045-330M 33 20 17 2.52 9 0.188 1.4 1.5 Coating .................Magnetic epoxy resin SRN6045-470M 47 20 13 2.52 7 0.257 1.1 1.3 Packaging ..... 1000 pcs. per 13-inch reel SRN6045-680M 68 20 13 2.52 6 0.351 0.9 1.0 SRN6045-101M 100 20 22 0.796 5 0.494 0.7 0.8 How to Order SRN6045-221M 220 20 25 0.796 4 1.18 0.6 0.7 SRN6045 - 100M Model Recommended Layout Electrical Schematic Value Code (see table) 2.3 REF. (.091) Product Dimensions 6.0 0.2 (.236 .008) 6.0 REF. (.236) 6.0 0.2 2.0 2.0 REF. REF. (.236 .008) (.079) (.079) 4.5 2.5 MAX. (.177) REF. (.098) WARNING Cancer and Reproductive Harm - www.P65Warnings.ca.gov * RoHS Directive 2015/863, Mar 31, 2015 and Annex. ** Bourns considers a product to be halogen free if (a) the Bromine (Br) content is 900 ppm or less (b) the Chlorine (Cl) content is 900 ppm or less and (c) the total Bromine (Br) and Chlorine (Cl) content is 1500 ppm or less. MM 2.3 Specifications are subject to change without notice. REF. DIMENSIONS: (INCHES) (.091) Users should verify actual device performance in their specific applications. The products described herein and this document are subject to specific legal disclaimers as set forth on the last page of this document, and at www.bourns.com/docs/legal/disclaimer.pdf. 6.0 REF. (.236) 2.0 2.0 REF. REF. (.079) (.079) SRN6045 Series - Semi-shielded Power Inductors SRF0504 Series - Line Filter Peak Temperature 250 max. Max. Peak Temperature -5 30 sec. max. Soldering Profile Max. Time Above 217 : 60~150 sec. max. Temperature Preheat Reflow Forced Rising Area Area Area Cooling Area +4.0 C/Sec. Max. 150~200 C / 60~120 Sec. +3.0 C/Sec. Max. -(1.0~5.0) C/Sec. Max. Peak Temperature: 250 C 250 Peak Temperature 217 C 250 max. 60~150 Sec. 200 Max. Peak Temp. -5 C 60 Sec. Max. 30 sec. max. 150 60~120 Sec. Max. Time Above 217 : 100 60~150 sec. max. 50 0 50 100 150 200 250 Time (Seconds) Packaging Specifications 330 2.0 0.5 DIA. 22.4 (12.992) (.079 .020) (.881) 13.0 0.5 21.0 0.8 (.512 .020) (.827 .031) DIA. 50.0 -0 (1.97 -0) 13.0 0.5 DIA. (.512 .020) 18 +0 16.0 (.709 +0) (.630) 12.0 4.0 (.472) (.157) END START LEADER COMPONENTS TRAILER 200 400 (7.874) (15.748) MIN. MIN. USER DIRECTION OF FEED NO COMPONENT NO COMPONENT QTY: 1000 PCS. PER REEL MM DIMENSIONS: (INCHES) REV. 01/20 Specifications are subject to change without notice. Users should verify actual device performance in their specific applications. The products described herein and this document are subject to specific legal disclaimers as set forth on the last page of this document, and at www.bourns.com/docs/legal/disclaimer.pdf. Temperature (C)
