Power Relays Type CS30/CF30 Monostable Compressor control relay Switching capacity 30A DC coils 6 to 48VDC AC coils 24 to 277VAC 2 normally open contacts, 2 change over contacts Reinforced insulation 4kV / 8mm (0.31) Meets class F construction PCB or Fast-on terminal General purpose, power loads Standard as sealed CE, UL approved CS30 CF30 Product Description Ordering Key C S30 A 002 12 Relay high power output. vending machines, and Type It is sealed designed for compressors load. Terminal version (S30= Soldering - F30= Fast-on) Coil version (A=AC - D=DC) Contact code Coil code Approvals The approvals stated are Box content: 20 relays not generally applicable Box size: (W 290 x D 240 x H 40) mm Weight: 2.000g to all relay versions of a (W 11.42 x D 9.45 x H 1.57) inches Weight: 70.55oz E60304 particular type. Type Selection Contact configuration Contact rating Contact code 2 normally open contact (DPST 2-form A ) 30A 200 2 change over contact (DPDT 2-form C ) 30A 002 Coil Characteristics, DC +20C (+68F) Coil Characteristics, AC +20C (+68F) 50/60Hz Rated Pick-up Drop-out Max. Rated Pick-up Drop-out Max. Coil Coil Coil Coil voltage voltage voltage Allowable resistance voltage voltage voltage Allowable resistance Code Code 10% 10% VDC VDC VDC voltage DC VAC VAC VAC voltage AC 5 5 3.8 0.5 5.5 15.3 24 24 19.2 4.8 26.4 39 6 6 4.5 0.6 6.6 22 120 120 96.0 24.0 132.0 950 1 12 12 9.0 1.2 13.2 86 208B 208 166.4 41.6 228.8 2841 2 24 24 18.0 2.4 26.4 350 220 220 175 44.0 242.0 3800 48 48 36.0 4.8 52.8 1390 240 240 192.0 48.0 264.0 3800 110 110 83 11 121 7255 277 277 211.6 55.4 304.7 5485 1 Only 60Hz 2 Contact Characteristics Only 50Hz 200 002 (NO) (NO) (NC) UL rating 30A - 277VAC 30A - 277VAC 3A - 277VAC 2.5HP - 240VAC 2.5HP - 240VAC 2.5HP - 240VAC 1HP - 120VAC 1HP - 120VAC 1HP - 120VAC TV 10 110LRA / 25.3FLA - VDE rating 30A - 250VAC 30A - 250VAC 3A - 250VAC Contact rating 30A - 277VAC 30A - 277VAC 3A - 277VAC Material AgSnO2 AgSnO2 Initial contact resistance 50m max. (1A-6VDC) 50m max. (1A-6VDC) Current Max. switching current 30A 30A Max. switching power 8.310VA 8.310VA Voltage Max. switching voltage 30VDC / 277VAC 30VDC / 277VAC Life 5 5 Electrical life 1 x 10 ops/min. 1 x 10 ops/min. 6 6 Mechanical life 5 x 10 ops/min. 5 x 10 ops/min. 1 Specifications are subject to change without notice. Pictures are just an example. For special features and/or customization, please ask to our sales network. 0824Power Relays Type CS30/CF30 Monostable Insulation Test voltage (1 min.) Surge voltage Open contacts 4000Vrms Contacts/coil 10000VAC Contacts/coil 1500Vrms Initial insulation resistance Contact/poles 2000Vrms 500VDC 1000M General Data Nominal coil power AC version 4VA Temperature rise AC 85C (+185F) max. DC version 1.7W DC 60C (+140F) max. 2 Operate time at nom. voltage 15ms Shock resist. Malfunction 100m/s 2 Mechanical 1000m/s Release time at nom. voltage 10ms Humidity 35% to 85%, +40C Ambient temperature AC -40 to +65C (-40 to +149F) DC -55 to +85C (-67 to +185F) Weight ~86g (~3.03oz) Vibration resistance 1.65mm (0.06) p.p. 10 to 55Hz Enclosure IP 67 Sealed Dimensions mm/inches Wiring Diagram SOLDER SIDE CS30 . 200/002 . CS30 . 200 . CS30 . 002 . 34.54/1.35 16/0.63 30.48/1.2 25.4/1 3.96/0.15 SOLDER SIDE CF30 . 200/002 . CF30 . 200 . CF30 . 002 . 34.54/1.35 26.42/1.04 16/0.63 1.8/0.07 4.58/0.18 37.72/1.48 25.4/1 Pin View mm/inches Diagram SOLDER SIDE SOLDER SIDE 1 Ambient temperature CS30 . 200/002 . CF30 . 200/002 . 5.16/0.203 140 120 DC coil, NO load 100 80 AC coil, load 30A AC coil, NO load 60 40 DC coil, load 30A 20 0.8/0.03 4.7/0.18 0 75 80 85 90 95 100105 110 115 120 125 130 135 140 145 150 0.8/0.03 4.7/0.18 Coil voltage (V%) Specifications are subject to change without notice. Pictures are just an example. For special features and/or customization, please ask to our sales network. 0824 2 4.12/0.16 1.83/0.07 1.19/0.05 6.35/0.25 0.8/0.03 1.32/0.05 6.4/0.25 7.85/0.31 52.32/2.06 52.32/2.06 7.85/0.31 14.86/0.58 59.71/2.35 41.1/1.62 41.1/1.62 4.12/0.16 6.35/0.25 7.85/0.31 7.85/0.31 14.86/0.58 14.86/0.58 7.85/0.31 14.86/0.58 Allowed temperature (C)
