Data Sheet SENCITY Rondo 600 MIMO Antenna 1399.31.0007 Description Indoor DAS omni-directional antenna for In-Building Coverage 617 MHz up to 4200 MHz AMPS, GSM, PCS, CDMA, UMTS, WiFi, WLAN 2.4, LTE Antenna ETL tested for Plenum space (UL 2043) Design Patent DM/088510 Product Configuration Technical Data Electrical Data Band 1 Band 2 Band 3 Band 4 Frequency (MHz) 617 - 698 698 - 790 790 - 960 1695 - 2180 VSWR 1.8 1.9 2 1.6 Impedance (Ohm) 50 50 50 50 Gain (dBi) 2.5 3.5 4.5 5 Composite power max (W) 50 Ambient temperature (C) 55 Port Isolation (dB) 13 15 17 20 Band 5 Band 6 Band 7 Band 8 Frequency (MHz) 2180 - 2400 2400 - 2500 2500 - 2690 3300 - 4200 VSWR 1.6 1.5 1.5 2 Impedance (Ohm) 50 50 50 50 Gain (dBi) 6 6.5 6.5 5.5 Port Isolation (dB) 18 18 18 21 Ports Port 1 Port 2 Connector 4.3-10, jack (female) 4.3-10, jack (female) SUCOFORM 141 C SUCOFORM 141 C Cable Type U CMP U CMP Cable Length (m) 0.35 0.35 Min. radius static 8 8 (mm) Polarization vertical vertical DC grounded Yes Yes Connections Band 1 Band 2 Band 3 Band 4 Band 5 Band 6 Band 7 Band 8 Port 1 X X X X X X X X Port 2 X X X X X X X X General Data IMD level -155 dBc at carrier power 2x 43dBm Gain specification defined without use of ground plane. Radiator grounded for remote connectivity surveillance Document: DOC-0000760885 O / PDO I / date of publication: 14.04.2021 17:38:29 / uncontrolled copy Page 1/2Data Sheet SENCITY Rondo 600 MIMO Antenna 1399.31.0007 Mechanical Data Dimensions (mm) 87 x 238 (Height x Diameter) Weight (kg) 0.82 Environmental Data Environmental conditions indoor Operation temperature (C) 0 to 55 Storage temperature (C) -55 to 85 Transport temperature (C) -55 to 85 Flammability rating UL 94-V0 Solar radiation UL 746C, F1 2011/65/EU (RoHS - including compliant 2015/863 and 2017/2102) Lead-free soldered yes REACH 1907/2006/EC compliant Plenum rated pigtail cable (UL2043) Material Data Radome colour white Radome material PC (Polycarbonate) Back plate/base plate material PCB 1 Related Products 9091.99.0258 Multi function bracket for SENSITY Rondo Thickness of false ceiling to be < 30 mm. Related Documents Mounting instruction DOC-0000717099 Painting instruction DOC-0000256180 Security instruction DOC-0000278984 Outline drawing DOU-00304163 Additional Information HUBER+SUHNER is certified according to ISO 9001, ISO 14001, AS/EN9100, ISO/TS 16949 and IRIS. www.hubersuhner.com Waiver: Fact and figures herein are for information only and do not represent any warranty of any kind. Document: DOC-0000760885 O / PDO I / date of publication: 14.04.2021 17:38:29 / uncontrolled copy Page 2/2
