CA121003-1703 ITT

ca A1-A163.qxd:Layout 1 2/9/11 7:48 PM Page 1Circular ca A1-A163.qxd:Layout 1 2/9/11 7:51 PM Page 149 CA-COM Introduction A ITT, Interconnect Solutions connec- tions series CA-COM and CA-COM-B are derivations of connectors accord- ing to MIL-C-5015 or VG95234. They were developed especially for indus- trial applications. Connectors of both CA-COM series are interchangeable with the corresponding types as per MIL-C-5015 and VG95234, as they offer the same mounting dimensions and contact arrangements. The entire CA-COM connector line is RoHS compliant. The CA-COM and CA-COM-B connec- tor series offer: Wall mounting receptacles CA-COM-B CA-COM Cable connecting plugs Box mounting receptacles Bayonet coupling Thread coupling Straight plugs Mateable with all connectors Mateable with all connectors Plugs 90 according to VG95234 and series according to MIL-C-5015 and CA-B respectively series CA respectively Wall mounting receptacles and cable Either solder or crimp contacts Either solder or crimp contacts connecting plugs (straight and 90) Contact arrangements with 1 to Contact arrangements with 1 to 37 are available with: 37 contacts contacts Wire sizes from 0,14 to 2,5 mm2 Wire sizes from 0, 14 up to Endbell with cable clamp Resilient insulator (polychloro- 2,5 mm2 Endbell for flex tubes prene) for wide temperature range Shells made of aluminum alloy Adapter combined for PG and (-55/125C) enable to withstand high metric terminations acc. To DIN Resistant againsts aggressive fluids mechanical strain* 46320 like fuel, oil, etc. Resilient insulator (polychloro- Adapter for heat shrink boots Environmental by means of an prene) for wide temperature range adaptor for PG termination, (-55/125C) Furthermore Cannon also provides universal endbell and heat Resistant against aggressive fluids the appropriate accessories, like: shrink boots like fuel, oil, etc. Min 500 mating cycles Environmental by means of an Protective metal caps Waterproof IP67 (with grommet) adaptor for PG termination, univer- Cable clamps sal endbell and heat shrink boots Cable bushings Min 500 mating cycles Sealing gaskets NOTE: *Receptacle size 14S and bar- Spray-waterproof IP65 (with grom- rel size 18 + 20 are made of Zinc met) dicast material. Aluminum versions available upon request Dimensions shown in inches (mm) Specifications and dimensions subject to change www.ittcannon.com A-149
