HyperLink Wireless brand 900 MHz Full Band Ultra High Q 4-Pole Indoor and Outdoor Bandpass Filters Features Ultra-High Quality Microwave Cavity Filter Ultra Low Insertion Loss (0.5 dB nominal) Reduce Interference and Improve Performance Outdoor Model: BPF900A Industrial Grade Rugged Aluminum Construction Indoor and Outdoor Models Provides Lightning Protection (DC Short) Ideal for 902-928 MHz ISM band applications Compact Size N-Female Connectors Optional Mast Mounting Kit Available for Outdoor Model Indoor Model: BPF900 Description The HyperLink 900 MHz 4-Pole Ultra-High Q full band filter is designed for full band applications. By reducing interference outside the 915 MHz band such as from cellular and paging signals, improved performance in noisy environments can be achieved. The BPF900 series filters are ideal for use with 902-928 MHz ISM band applications, 900 MHz RFID applications as well as 900 MHz ZigBee applications. Both these filters feature rugged aluminum construction. The BPF900 is designed for indoor use. For outdoor use choose the BPF900A. Specifications Models: BPF900 (Indoor) BPF900A (Outdoor) Center Frequencies 915 MHz Out of Band Rejection > 40 dB 815 MHz > 40 dB 1015 MHz Bandwidth 35 MHz Insertion Loss 0.5 dB nominal Passband Ripple < 0.25 dB Return Loss > 15 dB Impedance 50 Ohm Power Handling 50 Watts Connectors (2) N-Female Number of Cavities 4 Operating Temperature -40 F to 185 F (-40 C to +85 C) Dimensions 2.2 x 2.2 x 1.5 (56 x 56 x 40 mm) 2.9 x 2.9 x 1.9 (74 x 74 x 50 mm) rd L-com, Inc. 50 High St., West Mill, 3 Floor, Suite 30 North Andover, MA 01845 www.L-com.com E-mail: sales L-com.com Phone: 1-800-343-1455 Fax: 1-978-689-9484 L-com, Inc. All Rights Reserved. L-com Global Connectivity and the L-com logo are registered marks. Insertion Loss / Return Loss Plots Optional Mast Mounting Kit Model HGX-PMT14: Mast Mounting Kit for HyperLink outdoor filters. For mounting to 1-1/4 (31.7mm) to 2 (51mm) dia. masts. This kit contains an aluminum mounting bracket, zinc plated steel 1/4-20 x 2 u-bolt with serrated flange nuts and filter mounting hardware. Bandpass Filter Q & A Question: Why do I need a Hyperlink Ultra High Q band pass filter Answers: To reduce interference thus improving radio reception. To increase performance of co-located equipment. Question: What is interference and why do I want to eliminate it Answers: Interference is caused by transmission sources near the band you are transmitting on. It can be identified by signal strength and frequency. Unwanted transmissions, interference, may confuse your receiver or cover up the signal you are trying to receive. Question: How do the Hyperlink Ultra High Q band pass filters work Answers: The filter will only pass the frequency range you are transmitting or receiving and reduce the interference of signals outside your band. The filter will NOT reduce interference within your frequency band caused by other signals or users within the same band. Question: What is meant by frequency band filtering Answers: The passing of frequency band while rejecting all other frequency bands. The protection against signals outside your band such as cellular. rd L-com, Inc. 50 High St., West Mill, 3 Floor, Suite 30 North Andover, MA 01845 www.L-com.com E-mail: sales L-com.com Phone: 1-800-343-1455 Fax: 1-978-689-9484 L-com, Inc. All Rights Reserved. L-com Global Connectivity and the L-com logo are registered marks.
