Directional ay gi antennas y(B)4505 Innovative Technology for a Connected World Gold series directional Ya Gi antennas vide pro industr Y-leadinG desiGn Ftures ea with Glon term optimal perFormance Laird Technologies premium series directional Yagi antennas are fully gold anodized for corrosion resistance. All UHF and above frequency antennas feature internal matching to assure broad bandwidth and resistance to severe weather conditions. There is no gamma match to ice up, corrode or detune. Our engineering staff has optimized the product family for forward gain by computer analysis and then field-tested each for conformance. Features and BeneFits: tions:applica All UHF and higher frequency antennas feature 360 P oint-to-point and multi-point / omnidirectional welds around each element and an end-of-boom outdoor antennas applications used by private N connector feed with an internal transmission line organizations and government agencies around feeding the driven element. the globe. Every Yagi is tuned on a network analyzer for best T ypical applications include transportation such power match and lowest VSWR. as railroad switching, remote locations reporting All Yagi antennas ship complete with a high quality cast examples that include oil fields, weather conditions aluminum mounting kit that includes stainless steel and, meter data transmissions for utilities. hardware and allows vertical or horizontal orientation during installation (VHF models require light assembly). electrical Frequency Range 450 470 MHz Gain 9.2 dB2 Front - Back Ratio 20 dB Maximum Power 500 W 50 ohms Input Impedance Mechanical Elements 5 Vertical-to-Vertical Polarization azimuthal Pattern (y , Z, or e-plane) 3/8 Diameter solid 6061-T6 Element Material aluminum rod Heat treated 6061-T6 Boom Element aluminum tube Assembly Fully welded Length 37 Shipping All models are UPS shippable Mounting Up to 2 mast Hardware Stainless steel N female at the end of the Termination Type boom Lightning Protection DC grounded global solutions: local support Horizontal-to-Horizontal Polarization tM Rated Wind Velocity: 100 mph azimuthal Pattern (y , Z, or H-plane) Americas: +1.847 839.6907 IAS-AmericasEastSales lairdtech.com Europe: +1.32.80.7866.12 IAS-EUSales lairdtech.com ANT-DS-Y(B)4505 0610 Asia: +1.65.6.243.8022 Any information furnished by Laird Technologies, Inc. and its agents is believed to be accurate and reliable. All specifications are subject to change without notice. Responsibility for the use and application of Laird Technologies materials rests with the end user, since Laird Technologies and its agents cannot be aware of all potential uses. Laird Technologies makes no warranties as to the fitness, merchantability or suitability IAS-AsiaSales lairdtech.com of any Laird Technologies materials or products for any specific or general uses. Laird Technologies shall not be liable for incidental or consequential damages of any kind. All Laird Technologies products are sold pursuant to the Laird Technologies Terms and Conditions of sale in effect from time to time, a copy of which will be furnished upon request. Copyright 2010 Laird Technologies, Inc. All Rights Reserved. Laird, Laird Technologies, the Laird Technologies Logo, and other marks are trade marks or registered trade marks of Laird Technologies, Inc. or an affiliate company thereof. Other product or service names may be the www.lairdtech.com property of third parties. Nothing herein provides a license under any Laird Technologies or any third party intellectual property rights.X-ON Electronics Largest Supplier of Electrical and Electronic Components Click to view similar products for Antennas category: Click to view products by Laird Connectivity manufacturer: Other Similar products are found below : GAN30084EU 930-033-R GW17.07.0250E 1513563-1 EXE902SM APAMPG-117 MAF94383 W3908B0100 W6102B0100 YE572113- 30RSMM 108-00014-50 66089-2406 SPDA17RP918 A09-F8NF-M A09-F5NF-M RGFRA1903041A1T W3593B0100 W3921B0100 SIMNA-868 SIMNA-915 SIMNA-433 W1044 W1049B090 A75-001 WTL2449CQ1-FRSMM CPL9C EXB148BN 0600-00060 TRA9020S3PBN-001 Y4503 GD5W-28P-NF MA9-7N GD53-25 GD5W-21P-NF C37 MAF94051 MA9-5N EXD420PL B1322NR QWFTB120 MAF94271 MAF94300 GPSMB301 FG4403 AO-AGSM-OM54 5200232 MIKROE-2349 WCM.01.0111 MIKROE-2393 MIKROE-2352
