MC24005A6W-SPTLY

Address:MidasComponenntsLtd,ElectraHouse,32SouthtoownRoad,GreatYYarmouth,Norfoolk,England,NR31ODU Email:salees midascompoonents.co.uk Website:wwww.midascompponents.co.uk Tel:+44(0)1493602602 Fax:+44(00)1493665111BOOKBINDING AREA DATASHEET STATEMENT DOC. 1. The following icons are absolutely designed by Midas independently in 2007-SEP. They are not in common use in the LCD industry yet but just used for marking out Midas products characteristics quickly and simply without any special meaning. Midas reserves the composing right and copyright. No one else is allowed to adopt these icons without Midas approval. 2. The ISO9001 logo used in this document is authorized by SGS (www.sgs.com). Midas had already successfully passed the strict and professional ISO9001:2000 Quality Management System Certification and got the certificate (No.: CN07/00404) 3. The technologies/techniques/crafts which denoted by the following icons are not exclusively owned by Midas, but also shared by Midas LCD strategic cooperators, however all these technologies/techniques/crafts have been finally confirmed by Midas professional engineers and QC department. 4. As the difference in test standard and test conditions, also Midas insufficient familiarity with the actual LCD using environment, all the referred information in this DATASHEET (including the icons) only have two functions: 4.1: providing quick reference when you are judging whether or not the product meets your requirements. 4.2: listing out definitely the tolerance. SAMPLE APPROVAL document rather than consider this DATASHEET as the standard for judging whether or not the LCD meets your requirements. Once you instruct Midas to a mass-production without definite demand for providing sample before, Midas will disclaim all responsibility if the mass-production is proved not meeting with your requirements. 5. The sequence of the icons is random and doesnt indicate the importance grade. 6. Icons explanation Midas 2006 version logo.Midas is an integrated manufacturer of flat panel display (FPD). Midas supplies TN, HTN, STN, FSTN monochrome LCD panel COB, COG, TAB LCD module and all kinds of LED backlight. FAST RESPONSE TIME PROTECTION CIRCUIT This icon on the cover indicates the product This icon on the cover indicates the product FFF is with high response speed Otherwise not. is with protection circuit Otherwise not. HIGH CONTRAST LONG LIFE VERSION This icon on the cover indicates the product This icon on the cover indicates the product H C is long life version (over 9K hours guaranteed) is with high contrast Otherwise not. Otherwise not. WIDE VIEWING SCOPE Anti UV VERSION UV This icon on the cover indicates the product This icon on the cover indicates the product is with wide viewing scope Otherwise not. is against UV line. Otherwise not. RoHS COMPLIANCE OPERATION TEMPERATURE RANGE YC This icon on the cover indicates the product This icon on the cover indicates the operating XC meets ROHS requirements Otherwise not. temperature range (X-Y). RoHS 3TIMEs 100% QC EXAMINATION TWICE SELECTION OF LED MATERIALS This icon on the cover indicates the LED had passed This icon on the cover indicates the product Midas twice strict selection which promises the has passed Midas thrice 100% QC. products identical color and brightness Otherwise not. Otherwise not. Vlcm=3.0V N SERIES TECHNOLOGY (2008 developed) 3.0V N ew structure, new craft, new This icon on the cover indicates the product technology and new materials inside both LCD can work at 3.0V exactly otherwise not. N module and LCD panel to improve theRainBo
