This document was generated on 02/16/2020 PLEASE CHECK WWW.MOLEX.COM FOR LATEST PART INFORMATION Part Number: 1300100238 Status: Active Overview: Brad Mini-Change Connectors Description: Mini-Change A-Size Double-Ended Cordset, 3 Poles, Male (Straight) to Female (Straight), 16 AWG, PVC Cable, 6.10m (20.0 ) Length Documents: Drawing (PDF) RoHS Certificate of Compliance (PDF) Agency Certification Series image - Reference only CSA LR6837 UL E152210 EU ELV General Not Relevant Product Family Industrial Cordsets Series 130010 EU RoHS China RoHS Connector End A Mini-Change Not Reviewed Connector End B Mini-Change REACH SVHC IP Rating IP67 Not Reviewed Material - Contact Copper Alloy Halogen-Free Overview Brad Mini-Change Connectors Status Product Name Mini-Change Not Reviewed Protocol N/A For more information, please visit Contact US Region America China ROHS Not Reviewed Type Double Ended ELV Not Relevant UPC 78678843781 RoHS Phthalates Not Reviewed Physical Cable Diameter 10.41mm (.410 ) Cable Length 6.10m (20.0 ) Search Parts in this Series Color - Cable Jacket Yellow 130010 Series Coupling Style Threaded Gender Female-Male Keyway Single LED Indicator No Material - Cable Jacket PVC Material - Connector Body PVC Material - Coupling Nut Black Epoxy Coated Zinc Material - Plating Mating Gold Net Weight 894.483/g Orientation Straight to Straight Poles 3 Temperature Range - Operating -20C to +105C Wire Size AWG 16 Wire/Cable Type STOOW Electrical Current - Maximum per Contact 13.0A Voltage - Maximum 600V Material Info Engineering Number 113020A01F200 Reference - Drawing Numbers Sales Drawing SD-130010-002This document was generated on 02/16/2020 PLEASE CHECK WWW.MOLEX.COM FOR LATEST PART INFORMATION
