280035 Mountz

Making a Safer World Through Accuracy and Precision Product Bulletin Follow us on Twitter mountztorque PB 0057 (Rev2) June 2015 www.mountztorque.com EPT Click Wrench (Adjustable) - Designed and manufactured to meet or exceed the accuracy and repeatability of ISO 6789:2003 (Tools < 10 N.m (+/- 6% of setting): EPT100i (Tools > 10 N.m are +/- 4% of setting): EPT250i - EPT750F - Durable and robust for industrial fastening applications. - Adjustable torque wrench with a square drive. Bi-directional ratchet head. - External dual scale (American & S.I.) Graduation collar on the torque handle. - Easy to read laser marked scale. - Crafted with strong steel shaft with high corrosion resistance. - Lightly knurled non-slip grip. - 48 tooth ratchet (for models EPT250i - EPT750F). 60 tooth ratchet (for EPT100i) New model: EPT100i - Positive lock with spring loaded pull-down ring. - Positive click can be heard and felt when torque is reached. Torque Ranges Graduation Length Weight Model Item American S.I. American S.I. Square Drive in mm lbs kg EPT100i 280050 20 - 100 lbf.in 2.8 - 11.9 N.m 0.5 lbf.in 0.1 N.m 1/4 7 1/2 193 0.4 0.18 EPT250i-D 280033 50 - 250 lbf.in 6.2 - 28.8 N.m 1 lbf.in 0.1 N.m 1/4 9 2/3 245 0.9 0.4 EPT250i-A 280034 50 - 250 lbf.in 6.2 - 28.8 N.m 1 lbf.in 0.1 N.m 3/8 9 2/3 245 0.9 0.4 EPT75F 280035 15 - 75 lbf.ft 23.7 - 105.1 N.m 0.5 lbf.ft 0.5 N.m 3/8 16 1/8 410 2.6 1.2 EPT150F 280036 10 - 150 lbf.ft 20.3 - 210.1 N.m 1 lbf.ft 1 N.m 1/2 20 1/2 520 3.5 1.6 EPT250F 280037 30 - 250 lbf.ft 47.4 - 345.7 N.m 2 lbf.ft 2 N.m 1/2 24 610 3.5 1.6 EPT400F 280038 80 - 400 lbf.ft 142.3 - 559.2 N.m 2.5 lbf.ft 2.5 N.m 3/4 39 7/8 1012 10.9 4.9 EPT550F 280039 110 - 550 lbf.ft 183 - 779.5 N.m 2.5 lbf.ft 5 N.m 3/4 44 1/4 1125 12.6 5.7 EPT750F 280040 150 - 750 lbf.ft 237.2 - 1050.6 N.m 5 lbf.ft 5 N.m 1 48 1/4 1225 14.4 6.5 Note - After being used, an adjustable click wrench should be turned back to minimum scale value. This helps to preserve the springs and ensures a longer product life cycle with high precision. Page 1 Corporate Headquarters: 1080 North 11th Street, San Jose, CA 95112 X-ON Electronics Largest Supplier of Electrical and Electronic Components Click to view similar products for Mountz manufacturer: Other Similar products are found below : 280041 145754 145866 EPT250I-A 280034 020066 068106 280035
