PZU18B,115 Nexperia

PZUxB series Zener diodes in a SOD323F package Rev. 5 2 November 2020 Product data sheet 1. General description General-purpose Zener diodes in a SOD323F (SC-90) very small and flat lead Surface Mounted Device (SMD) plastic package. 2. Features and benefits Total power dissipation: 550 mW Tolerance series: B: approximately 5 % B1, B2, B3: sequential, approximately 2 % Small plastic package suitable for surface mounted design Wide working voltage range: nominal 2.4 V to 36 V Very low leakage current for a given reverse voltage for types PZU5.1B - PZU10B AEC-Q101 qualified 3. Applications General regulation functions 4. Quick reference data Table 1. Quick reference data Symbol Parameter Conditions Min Typ Max Unit V forward voltage I = 10 mA 1 - - 0.9 V F F P total power dissipation T 25 C 2 - - 550 mW tot amb 1 Pulse test: t 300 s 0.02 p 2 2 Device mounted on an FR4 PCB, single-sided copper, tin-plated, mounting pad for cathode 1cm .Nexperia PZUxB series Zener diodes in a SOD323F package 5. Pinning information Table 2. Pinning Pin Description Simplified outline Symbol 1 cathode 1 1 2 1 2 2 anode sym068 1 The marking bar indicates the cathode 6. Ordering information Table 3. Ordering information Type number Package Name Description Version PZU2.4B to SC-90 plastic surface mounted package 2 leads SOD323F PZU36B 1 1 The series consists of 97 types with nominal working voltages from 2.4 V to 36 V. 7. Marking Table 4. Marking codes Type number Marking code Type number Marking code B B1 B2 B3 B B1 B2 B3 PZU2.4 G3 - - - PZU10 GJ FH HF KB PZU2.7 G4 F3 H1 - PZU11 GK FJ HG KC PZU3.0 G5 F4 H2 - PZU12 GL FK HH KD PZU3.3 G6 F5 H3 - PZU13 GM FL HJ KE PZU3.6 G7 F6 H4 - PZU14 - - HK - PZU3.9 G8 F7 H5 - PZU15 GN FM HL KF PZU4.3 G9 F8 H6 HS PZU16 GP FN HM KG PZU4.7 GA F9 H7 HT PZU18 GQ FP HN KH PZU5.1 GB FA H8 HU PZU20 GR FQ HP KJ PZU5.6 GC FB H9 HV PZU22 GS FR HQ KK PZU6.2 GD FC HA HW PZU24 GT FS HR KL PZU6.8 GE FD HB HX PZU27 GU - - - PZU7.5 GF FE HC HY PZU30 GV - - - PZU8.2 GG FF HD HZ PZU33 GW - - - PZU9.1 GH FG HE KA PZU36 GX - - - PZUXB SER All information provided in this document is subject to legal disclaimers. Nexperia B.V. 2020. All rights reserved Product data sheet Rev. 5 2 November 2020 2 / 12
