DATA SHEET www.onsemi.com EEPROM Serial 2 2/4/8/16 Kb I C UDFN8EP SOIC8 WIDE HU4 SUFFIX CAT24C02, CAT24C04, X SUFFIX CASE 517AZ CASE 751BE CAT24C08, CAT24C16 Description TSSOP8 The CAT24C02/04/08/16 are 2Kb, 4Kb, 8Kb and 16Kb TSOT23 2 Y SUFFIX respectively I C Serial EEPROM devices organized internally as TD SUFFIX CASE 948AL CASE 419AE 16/32/64 and 128 pages respectively of 16 bytes each. All devices 2 support both the Standard (100 kHz) as well as Fast (400 kHz) I C protocol. WLCSP4** Data is written by providing a starting address, then loading 1 to 16 C4A SUFFIX SOIC8 contiguous bytes into a Page Write Buffer, and then writing all data to W SUFFIX CASE 567DC nonvolatile memory in one internal write cycle. Data is read by CASE 751BD providing a starting address and then shifting out data serially while automatically incrementing the internal address count. WLCSP5** WLCSP4** External address pins make it possible to address up to eight C5A SUFFIX C4U SUFFIX CASE 567DD CASE 567NX CAT24C02, four CAT24C04, two CAT24C08 and one CAT24C16 device on the same bus. ** WLCSP are available for the CAT24C04, CAT24C08 and CAT24C16 only. Features For serial EEPROM in the US8 package, please 2 Supports Standard and Fast I C Protocol consult the N24C02 datasheet 1.7 V to 5.5 V Supply Voltage Range 16Byte Page Write Buffer ORDERING INFORMATION Hardware Write Protection for Entire Memory See detailed ordering and shipping information in the package 2 Schmitt Triggers and Noise Suppression Filters on I C Bus Inputs dimensions section on page 18 of this data sheet. (SCL and SDA) Low power CMOS Technology More than 1,000,000 Program/Erase Cycles 100 Year Data Retention Industrial and Extended Temperature Range These Devices are PbFree, Halogen Free/BFR Free and are RoHS Compliant This document contains information on some products that are still under development. onsemi reserves the right to change or discontinue these products without notice. Semiconductor Components Industries, LLC, 2016 1 Publication Order Number: August, 2021 Rev. 35 CAT24C01/DCAT24C02, CAT24C04, CAT24C08, CAT24C16 PIN CONFIGURATIONS AND MARKING INFORMATION V CC Table 1. PIN FUNCTION Pin Name Function A0, A1, A2 Device Address Input SCL SDA Serial Data Input/Output SCL Serial Clock Input A , A , A CAT24Cxx SDA 2 1 0 WP Write Protect Input WP V Power Supply CC V Ground SS NC No Connect V SS The exposed pad for the UDFN packages can be left floating or connected to Ground. Figure 1. Functional Symbol CAT24C 12 12 3 Pin 1 Pin 1 16 / 08 / 04 / 02 NC///NC NC 8 V A CC 0 1 A A V V V V CC SS CC SS /// NC NC WP A A 2 7 1 1 B SDA /// NC A A A 3 6 SCL 2 2 2 B SCL SDA WP SCL C V 4 5 SDA SS SOIC (W, X), TSSOP (Y), WLCSP4*** WLCSP5*** UDFNEP (HU4) (Top View) (Top Views) *** WLCSP are available for the CAT24C04, CAT24C08 and CAT24C16 only. TOP MARKING FOR WLCSP (Ball Down) 5 SCL WP 1 Pin 1 Pin 1 Pin 1 V 2 SS X X X SDA 3 4 V CC Y M Y W Y M TSOT23 (TD) (Top View) WLCSP4 WLCSP4 WLCSP5 (C4A) (C4U) X = Specific Device X = Code 4 or R = 24C04 8 or T = 24C08 6 or V = 24C16 Y = Production Year (Last Digit) M = Production Month (19, O, N, D) W = Production Week www.onsemi.com 2
