NCS2553DR2G ON Semiconductor

NCS2553 3-Channel Video Amp with Standard Definition Reconstruction Filters Description NCS2553 SD IN1 SD OUT1 Transparent Clamp 6dB 8 MHz, 6th Order Transparent Clamp SD IN2 6dB SD OUT2 8 MHz, 6th Order Transparent Clamp SD OUT3 SD IN3 6dB 8 MHz, 6th Order Figure 1. Block Diagram PIN FUNCTION AND DESCRIPTION Pin Name Type Description 1 IN1 Input Video Input 1 for Video Signal featuring a frequency bandwidth compatible with Standard Definition Video (8 MHz) Channel 1 2 IN2 Input Video Input 2 for Video Signal featuring a frequency bandwidth compatible with Standard Definition Video (8 MHz) Channel 2 3 IN3 Input Video Input 3 for Video Signal featuring a frequency bandwidth compatible with Standard Definition Video (8 MHz) Channel 3 4 VCC Power Device Power Supply Voltage: +5 V 5 GND GND Connected to Ground 6 OUT3 Output SD Video Output 3 Channel 3 7 OUT2 Output SD Video Output 2 Channel 2 8 OUT1 Output SD Video Output 1 Channel 1 ATTRIBUTES Characteristics Value ESD Human Body Model All Pins (Note 1) 8 kV Machine Model Pins 1 to 5 (Note 2) 400 V All Output Pins (Note 2) 800 V Moisture Sensitivity (Note 3) Level 1 Flammability Rating Oxygen Index: 28 to 34 UL 94 V0 0.125 in 1. Human Body Model (HBM): R = 1500 , C = 100 pF 2. Machine Model (MM) 3. For additional information, see Application Note AND8003/D.
