MCR-C-UI-UI-DCI-NC

MCR-C-UI-UI(-450)-DCI(-NC) 3-way isolation amplifier INTERFACE Data Sheet 100238 en 02 PHOENIX CONTACT - 01/2008 Features Description The MCR-C-UI-UI(-450)-DCI(-NC) 3-way isolation amplifier Configurable 3-way isolating amplifiers is used to electrically isolate and convert analog signals. The Input and output signal range can be configured via DIP device provides electrical isolation of analog standard sig- switches nals. The module input and output are supplied via integra- ZERO/SPAN adjustment using potentiometers ted DC/DC converters, which are electrically isolated from Can be supplied configured or unconfigured the mains (3-way isolation). The required auxiliary voltage is indicated via a green power LED. This clearly indicates whether or not auxiliary voltage is available. The MCR module ensures the safe decoupling of a sensor circuit from the evaluation circuit and also prevents the nega- tive effects of several sensor circuits connected with one another. 3-way isolation enables the universal use of modu- les both locally and close to the control system for signal con- version and electrical isolation, as well as on the transmis- sion path for jumpering high load resistors. Signals are converted by an inductive transmission method. In addition, a filter connected downstream of the transmitter reduces possible interference. WARNING: Correct usage in potentially explosive areas The module is a category 3 item of electrical equipment. Follow the instructions provided here during instal- lation and observe the safety instructions. Make sure you always use the the latest documentation. It can be downloaded at www.download.phoenixcontact.com. A conversion table is available on the Internet at www.download.phoenixcontact.com/general/7000 en 00.pdf This data sheet is valid for all products listed on the following page:MCR-C-UI-UI(-450)-DCI(-NC) Ordering data Description Type Order No. Pcs./Pkt. 3-way isolation amplifier , Pluggable COMBICON screw connection , with MCR-C-UI-UI-DCI 2810913 1 a limit frequency (3 dB) 30 Hz, configured 3-way isolation amplifier , Pluggable COMBICON screw connection , with MCR-C-UI-UI-450-DCI 2810887 1 limit frequency (3 dB) 450 Hz, without GL and UL approval, configured 3-way isolation amplifier , Pluggable COMBICON screw connection , with MCR-C-UI-UI-DCI-NC 2810939 1 a limit frequency (3 dB) 30 Hz, unconfigured Order key (standard configuration entered as an example) Order No. Input Output Factory Calibration Certificate 2810913 / IN03 / OUT03 / NONE 2810913 = IN01 = 0 ... 20 mA IN18 = -1 ... +1 V IN28 = 0 ... 500 mV OUT01 = 0 ... 20 mA NONE = Without factory MCR-C-UI-UI-DCI IN02 = 4 ... 20 mA IN19 = -2 ... +2 V IN29 = 0 ... 1 V OUT02 = 4 ... 20 mA calibration certi- IN03 = 0 ... 10 V IN20 = -2.5 ... +2.5 V IN30 = 0 ... 2 V OUT03 0 ... 10 V ficate 2810887 = IN05 = 0 ... 5 V IN21 = -5 ... +5 V IN31 = 0 ... 2.5 V OUT05 = 0 ... 5 V MCR-C-UI-UI-450-DCI IN06 = 1 ... 5 V IN22 = -10 ... +10 V IN32 = 0 ... 20 V OUT06 = 1 ... 5 V YES = With factory ca- IN13 = -60 ... +60 mV IN23 = -20 ... +20 V IN33 = -5 ... +5 mA OUT13 = -5 ... +5 V libration certifi- IN14 = -100 ... +100 mV IN24 = 0 ... 60 mV IN34 = -10 ... +10 mA OUT14 = -10 ... +10 cate (a fee is IN15 = -200 ... +200 mV IN25 = 0 ... 100 mV IN35 = -20 ... +20 mA OUT15 = 0 ... 5 mA charged) IN16 = -300 ... +300 mV IN26 = 0 ... 200 mV IN36 = 0 ... 5 mA OUT16 = 0 ... 10 mA IN17 = -500 ... +500 mV IN27 = 0 ... 300 mV IN37 = 0 ... 10 mA YESPLUS = Factory calibra- tion certificate with 5 measuring points (a fee is charged) Combination Table for Input and Output Signals Voltage Output Current Output Input 0 ... 10 V 10 V 0 ... 5 V 5 V 1 ... 5 V 0 ... 5 mA 0 ... 10 mA 0 ... 20 mA 4 ... 20 mA 0 ... 60 mV xxxxxxxxx 0 ... 100 mV xxxxxxxxx 0 ... 200 mV xxxxxxxxx 0 ... 300 mV xxxxxxxxx 0 ... 500 mV xxxxxxxxx 0 ... 1 V xxxxxxxxx 0 ... 2 V xxxxxxxxx 0 ... 2.5 V xxxxxxxxx 0 ... 5 V xxxxxxxxx 0 ... 10 V xxxxxxxxx 0 ... 20 V xxxxxxxxx 60 mV xxxx x x 100 mV xxxx x x 200 mV xxxx x x 300 mV xxxx x x 500 mV xxxx x x 1 V xxxx x x 2 V xxxx x x 2.5 V xxxx x x 5 V xxxx x x 10 V xxxx x x 20 V xxxx x x 0 ... 5 mA xxxxxxxxx 0 ... 10 mA xxxxxxxxx 0 ... 20 mA xxxxxxxxx 5 mA xxxx x x 10 mA xxxx x x 20 mA xxxx x x 1 ... 5 V xxxxx xxx 4 ... 20 mA xxxxx xxx 100238 en 02 PHOENIX CONTACT 2
