GT11001-10.0M-EVAL Pletronics

GPS Synchronization Module User Manual Copyright 2020 Pletronics Inc. Rev: 2.0 Date: May 2, 2021 GPS Module Series User Manual 1 Introduction 1.1 Overview The GPS Module evaluation kit includes a GPS module with an evaluation board. The evaluation board is intended for use in evaluating the module. It allows for easy connection to the appropriate inputs and outputs. Section 2 of the guide identifies the various connections. 1.2 General Precautions The module is designed for 3.3 volt operation. If 5.0 volt is required, please contact factory for this option. The power supply for the evaluation board is 5.0V The maximum current is 0.2 a. Do not exceed the max- imum Vcc voltage as this could damage the unit. Proper grounding and ESD precautions should be main- tained when handling this and all electronic components. 1.4 GPS Module Series Pin-out The GPS module pin-out is in table 1-1. This defines the pin-out of the module. The pin-out for the test board is defined in section 2. The pads on the module and connections on the test board are not aligned. Pad Function 1 Ground 2 10 MHz Out 3 Lock OK 4 1 PPS Output 5 1 PPS Input 6 + 5V Output 7 Ground 8 +3.3V VDO In 9 Ground 10 Antenna Input 11 Ground 12 NMEA Transmit 13 1PPS Enable 14 N/C 15 N/C Copyright 2021 Pletronics Inc 2
