PP000655 Pro Power

Cable Multicore Product Description: Application For communication and signal control systems Reference Standard Customers sample spec.and the general standard Multi-construction Multi-core coaxial Cable Construction: 6 coaxial video cable spec Conductor 1 Tinned Copper Construction T0.10 0.005 7 Standard Dia. (mm) 0.3 Insulation 1 Solid PE Thickness (mm) 0.75 Insulation Dia. (mm) 1.8 0.1 Insulation Colour Natural Braiding 1 Bare Copper Construction (mm) 0.12 0.003 16 4 Coverage 80% Inner jacket 1 PVC Thickness(mm) 0.3 Dia.(0.15mm) 2.8 Jacket Colour Grey Black Red Green Blue White 4 Core Audio cable spec Conductor 2 Tinned Copper Construction T0.10 0.005 7 Standard Dia. (mm) 0.3 Insulation 2 Solid PE Thickness (mm) 0.37 Insulation Dia. (mm) 1.05 0.1 4C Insulation Colour Orange White Transparent Grey www.element14.com www.farnell.com www.newark.com www.cpc.co.uk Page <1> 18/02/15 V1.0Cable Multicore Product Description: Screening 2 Bare Copper Spiral Construction (mm) 0.12 0.005 32 Mylar tape Spiral Coverage 115% Inner jacket 2 PVC Thickness (mm) 0.6 Dia.(0.15mm) 4.2 Jacket Colour Ivory 2 Data Bus coaxial cable spec Conductor 3 Tinned Copper Construction T0.10 0.005 7 Standard Dia. (mm) 0.3 Insulation 3 Solid PE Thickness (mm) 0.37 Insulation Dia. (mm) 1.05 0.1 Insulation Colour Yellow Green Screening 3 Bare Copper Spiral Construction (mm) 0.12 0.005 32 Inner jacket 3 PVC Thickness (mm) 0.4 Dia.(0.15mm) 2.1 2 Jacket Colour Yellow Hook Up spec Conductor 4 Bare Copper Construction 0.10 0.005 18 Standard Dia. (mm) 0.49 Insulation 4 PVC Thickness (mm) 0.28 Insulation Dia. (mm) 1.05 0.05 Insulation Colour: Brown www.element14.com www.farnell.com www.newark.com www.cpc.co.uk Page <2> 18/02/15 V1.0
