CFM-6025CF-265-408-20 Same Sky

Additional Resources: Product Page date 10/18/2021 page 1 of 8 SERIES: CFM-60CF DESCRIPTION: DC AXIAL FAN FEATURES omniCOOL bearing system 60 x 60 mm frame multiple speed options tachometer signal available 2 4 input input input rated airflow static noise MODEL 1 1 1 3 voltage current power speed pressure rated range max max typ typ (Vdc) (Vdc) (A) (W) (RPM10%) (CFM) (inch H O) (dBA) 2 CFM-6015CF-225-204 24 21.6~26.4 0.04 0.96 2,5005 11.01 0.05 20.5 CFM-6015CF-235-278 24 21.6~26.4 0.06 1.44 3,5006 15.41 0.09 27.8 CFM-6015CF-245-332 24 21.6~26.4 0.11 2.64 4,5006 19.82 0.16 33.2 CFM-6015CF-255-375 24 21.6~26.4 0.15 3.60 5,5006 24.22 0.23 37.6 CFM-6025CF-035-274 5 4.5~5.5 0.39 1.95 3,500 16.76 0.11 27.5 CFM-6025CF-050-351 5 4.5~5.5 0.51 2.55 5,000 23.95 0.22 35.2 CFM-6025CF-135-274 12 10.8~13.2 0.15 1.80 3,500 16.76 0.11 27.5 CFM-6025CF-150-351 12 10.8~13.2 0.29 3.48 5,000 23.95 0.22 35.2 CFM-6025CF-165-408 12 10.8~13.2 0.50 6.00 6,500 31.13 0.37 40.9 CFM-6025CF-235-274 24 21.6~26.4 0.08 1.92 3,500 16.76 0.11 27.5 CFM-6025CF-250-351 24 21.6~26.4 0.14 3.36 5,000 23.95 0.22 35.2 CFM-6025CF-265-408 24 21.6~26.4 0.23 5.52 6,500 31.13 0.37 40.9 Notes: 1. At rated voltage, after 3 minutes. 2. At rated voltage, room temperature, 65% humidity, 0 inch H 0 static pressure. 2 3. At rated voltage, 0 CFM airflow. 4. Measured in an anechoic chamber as per ISO3745/GB4214-84 at rated voltage, with background noise 202 dBA at 1 m from the fan intake. 5. Typical rated speed is measured as RPM400 at rated voltage. 6. Typical rated speed is measured as RPM600 at rated voltage. 7. All specifications are measured at 25C, 65% relativ e humidity unless otherwise specified. PART NUMBER KEY CFM-6025CF-035-274- XX - CXX Fan Signals Base Number Reserved for Custom blank = no signals Configurations 20 = tachometer signal cuidevices.comAdditional Resources: Product Page CUI Devices SERIES: CFM-60CF DESCRIPTION: DC AXIAL FAN date 10/18/2021 page 2 of 8 INPUT parameter conditions/description min typ max units 5 Vdc input models 4.5 5 5.5 Vdc 8 operating input voltage 12 Vdc input models 10.8 12 13.2 Vdc 24 Vdc input models 21.6 24 26.4 Vdc 5 Vdc input models 4 Vdc starting voltage 12 Vdc input models 7 Vdc 24 Vdc input models 14 Vdc Note: 8. See Model section on page 1 for specific input voltage ranges. 9 PERFORMANCE parameter conditions/description min typ max units rated speed at rated voltage, 25C, after 3 minutes 2,500 6,500 RPM air flow at 0 inch H O, see performance curves 11.01 31.13 CFM 2 static pressure at 0 CFM, see performance curves 0.05 0.37 inch H O 2 noise at 1 m, rated speed 20.5 40.9 dBA Note: 9. See Model section on page 1 for specific values. 10 PROTECTIONS / FEATURES parameter conditions/description min typ max units auto restart on all models polarity protection on all models tachometer signal available on 20 models Notes: 10. See Application Notes for details. SAFETY & COMPLIANCE parameter conditions/description min typ max units insulation resistance at 500 Vdc between frame and positive terminal 10 M at 500 Vac, 60 Hz, 1 minute between housing and dielectric strength 5 mA positive terminal safety approvals UL/cUL 507, TUV (EN/IEC 62368-1:2020+A11) EMI/EMC EN 55032:2015, EN 55035:2017 life expectancy at 40C, 65% RH, 90% confidence level 70,000 hours RoHS yes ENVIRONMENTAL parameter conditions/description min typ max units operating temperature -10 70 C storage temperature -40 75 C operating humidity non-condensing 35 85 % storage humidity non-condensing 35 85 % cuidevices.com
