SMBJ18A Taiwan Semiconductor

SMBJ5V0(C)A SMBJ170(C)A Taiwan Semiconductor 600W Transient Voltage Suppressor FEATURES Glass passivated junction 600W peak pulse power capability on 10/1000s waveform Excellent clamping capability Low-Incremental surge resistance Fast response time: Typically less than 1.0ps from 0V to BV minimum for unidirectional and 5.0ns for bidirectional Typical I less than 1A above 10V R UL certificate E258596 SMB/DO-214AA Band denotes cathode on unidirectional devices only. No band on bi-directional devices. Bi-directional types have CA suffix where electrical chatacteristics apply in both directions suitable for bi-directional applications. ABSOLUTE MAXIMUM RATINGS Stresses exceeding the absolute maximum ratings may damage the device. The device may not function or be operable above the recommended operating conditions and stressing the parts to these levels is not recommended. In addition, extended exposure to stresses above the recommended operating conditions may affect device reliability. The absolute maximum ratings are stress ratings only. Values are at TA = 25C unless otherwise noted. PARAMETER SYMBOL VALUE UNIT Peak pulse power dissipation t =1ms P 600 W p PPM Peak pulse current on 10/1000s waveform I see table A PPM Non-Repetitive Peak Forward Surge Current (1) I 100 A FSM Superimposed on Rated Load (JEDEC Method) T -55 to +150 C Junction temperature J T -55 to +150 C Storage temperature STG Note: 1. Measured on 8.3ms single half-sine wave duty cycle = 4 pulses per minute maximum. 1 Version: B1910 SMBJ5V0(C)A SMBJ170(C)A Taiwan Semiconductor ELECTRICAL SPECIFICATIONS (T = 25C unless otherwise noted) A Breakdown Reverse Reverse Test Clamping Voltage Uni-directional Stand-Off Peak Pulse Leakage Part Current Voltage V Bi-directional (C) (2) Voltage BR Current Current Marking I at I T PPM (V) Device V I (A) at V RWM PPM RWM (mA) V (V) C (3) (V) I (A) R Min. Max. SMBJ5V0(C)A KE 5.0 6.4 7 10 9.2 65.2 800 SMBJ6V0(C)A KG 6.0 6.67 7.37 10 10.3 58.3 800 SMBJ6V5(C)A KK 6.5 7.22 7.98 10 11.2 53.6 500 SMBJ7V0(C)A KM 7.0 7.78 8.6 10 12.0 50 200 SMBJ7V5(C)A KP 7.5 8.33 9.21 1 12.9 46.5 100 SMBJ8V0(C)A KR 8.0 8.89 9.83 1 13.6 44.1 50 SMBJ8V5(C)A KT 8.5 9.44 10.4 1 14.4 41.7 20 SMBJ9V0(C)A KV 9.0 10 11.1 1 15.4 39 10 SMBJ10(C)A KX 10 11.1 12.8 1 17.0 35.3 5 SMBJ11(C)A KZ 11 12.2 13.5 1 18.2 33 5 SMBJ12(C)A LE 12 13.3 14.7 1 19.9 30.2 5 SMBJ13(C)A LG 13 14.4 15.9 1 21.5 27.9 5 SMBJ14(C)A LK 14 15.6 17.2 1 23.2 25.9 5 SMBJ15(C)A LM 15 16.7 18.5 1 24.4 24.6 5 SMBJ16(C)A LP 16 17.8 19.7 1 26.0 23.1 5 SMBJ17(C)A LR 17 18.9 20.9 1 27.6 21.7 5 SMBJ18(C)A LT 18 20 22.1 1 29.2 20.5 5 SMBJ20(C)A LV 20 22.2 24.5 1 32.4 18.5 5 SMBJ22(C)A LX 22 24.4 26.9 1 35.5 16.9 5 SMBJ24(C)A LZ 24 26.7 29.5 1 38.9 15.4 5 SMBJ26(C)A ME 26 28.9 31.9 1 42.1 14.3 5 SMBJ28(C)A MG 28 31.1 34.4 1 45.4 13.2 5 SMBJ30(C)A MK 30 33.3 36.8 1 48.4 12.4 5 SMBJ33(C)A MM 33 36.7 40.6 1 53.3 11.3 5 SMBJ36(C)A MP 36 40 44.2 1 58.1 10.3 5 SMBJ40(C)A MR 40 44.4 49.1 1 64.5 9.3 5 SMBJ43(C)A MT 43 47.8 52.8 1 69.4 8.6 5 SMBJ45(C)A MV 45 50 55.3 1 72.7 8.3 5 SMBJ48(C)A MX 48 53.3 58.9 1 77.4 7.8 5 SMBJ51(C)A MZ 51 56.7 62.7 1 82.4 7.3 5 SMBJ54(C)A NE 54 60 66.3 1 87.1 6.9 5 SMBJ58(C)A NG 58 64.4 71.2 1 93.6 6.4 5 SMBJ60(C)A NK 60 66.7 73.7 1 96.8 6.2 5 SMBJ64(C)A NM 64 71.1 78.6 1 103 5.8 5 SMBJ70(C)A NP 70 77.8 86 1 113 5.3 5 SMBJ75(C)A NR 75 83.3 92.1 1 121 5 5 SMBJ78(C)A NT 78 86.7 95.8 1 126 4.8 5 2 Version: B1910
