UTD1050DL Uni-T

Name: UTD1050DL
Brand: Uni-T
SKU: UTD1050DL_Uni-T
Availability: InStock
Rating: 5 (11 reviews)

Images are for reference only, See Product Specifications

X-On Electronics has gained recognition as a prominent supplier of UTD1050DL across the USA, India, Europe, Australia, and various other global locations. UTD1050DL are a product manufactured by Uni-T. We provide cost-effective solutions for UTD1050DL, ensuring timely deliveries around the world.

Part No.	UTD1050DL
Manufacturer:	Uni-T
Category:	Unclassified
Description:	Handheld oscilloscope; 50MHz; LCD TFT 3,5; Ch: 2; 250Msps; 12kpts
Datasheet:	UTD1050DL Datasheet (PDF)

Price (USD)

1: USD 607.1982 ea
Line Total: USD 607.2

Availability : 2

Ship by Wed. 08 Oct to Fri. 10 Oct

Qty Unit Price
1 $ 607.1982
4 $ 577.8864

UTD1050DL More Buying Options & Price Grid(s)

Please wait...

Availability

Price (USD)

Buy Price

Quantity

Availability 2

Ship by Wed. 08 Oct to Fri. 10 Oct

MOQ : 1
Multiples : 1

Qty Unit Price
1 $ 607.1982
4 $ 577.8864

Specifications

Manufacturer

Uni-T Uni-T

Product Category

Unclassified Unclassified

Kind Of Display Used

LCD TFT 3,5 LCD TFT 3,5

Power Supply

m A ins po W er supply , rech A rge A ble b A ttery Li - Ion 7 , 4 V 3600m A h x1 m A ins po W er supply , rech A rge A ble b A ttery Li - Ion 7 , 4 V 3600m A h x1

Interface

USB mini USB mini

Number Of Channels

2 2

Display Resolution

320x240 320x240

Dimensions

199x118x49mm 199x118x49mm

Standard Equipment

test leads, USB cable, test probe x1, mains cable, current shunt, mains adapter test leads, USB cable, test probe x1, mains cable, current shunt, mains adapter

Measuring Instrument Features

automatic measurement of many parameters automatic measurement of many parameters

Sampling

250Msps 250Msps

Type Of Oscilloscope

handheld oscilloscope handheld oscilloscope

Trigger

video signal, rising - edge, falling - edge, impulse width, slope video signal, rising - edge, falling - edge, impulse width, slope

Measurement

AC voltage, DC voltage, capacitance, DC current, resistance, AC current AC voltage, DC voltage, capacitance, DC current, resistance, AC current

Band

50MHz 50MHz

Rise Time

≤ 7 ns ≤ 7 ns

Input Sensitivity

5mV/div...20V/div 5mV/div...20V/div

Time Base

5n To 50s/div 5n To 50s/div

Ac Current Measuring Range

4 mA , 40 mA , 4 A , 0.4 mA 4 mA , 40 mA , 4 A , 0.4 mA

Resistance Measuring Range

4 kOhms hms , 40 kOhms hms , 400 kOhms hms , 4 MOhms , 40 MOhms , 0.4 kOhms hms 4 kOhms hms , 40 kOhms hms , 400 kOhms hms , 4 MOhms , 40 MOhms , 0.4 kOhms hms

Dc Current Measuring Range

40 mA , 4 mA , 4 A , 0.4 mA 40 mA , 4 mA , 4 A , 0.4 mA

Dc Voltage Measuring Range

400 V , 4 V , 40 V , 400 mV 400 V , 4 V , 40 V , 400 mV

Ac Voltage Measuring Range

400 V , 400 mV , 4 V , 40 V 400 V , 400 mV , 4 V , 40 V

Capacitance Measuring Range

100 uF , 512 nF , 5.12 uF , 51.2 uF , 51.2 nF 100 uF , 512 nF , 5.12 uF , 51.2 uF , 51.2 nF

Battery/ Rechargeable Battery

rechargeable battery Li - Ion 7 , 4V 3600mAh x1 rechargeable battery Li - Ion 7 , 4V 3600mAh x1

Memory Record Length

12 k pts 12 k pts

Display Parameters

(3999) (3999)

Capacitance Measuring Accuracy

± (3 % + 5 digit) ± (3 % + 5 digit)

Dc Voltage Measuring Accuracy

(1.2 % + 5 digit) (1.2 % + 5 digit)

Ac Voltage Measuring Accuracy

(1.2 % + 5 digit) (1.2 % + 5 digit)

Resistance Measuring Accuracy

± (1.2 % + 5 digit) , ± (1.5 % + 5 digit) @ (40 MOhms) ± (1.2 % + 5 digit) , ± (1.5 % + 5 digit) @ (40 MOhms)
