268525C Van Damme

cable Black Series Tour Grade speaker cable Van Damme Black Series Tour Grade Speaker Cable offers a comprehensive conductor size and core count to accommodate almost all potential speaker signals. From 2 core 1.5mm through 8 core 4mm to 18 core 2.5mm the ultra pure copper conductors, cutting edge PVC compounds and dynamic use focused construction provide accurate signal transmission, toughness and exibility. Applications Matt black jacket for on stage use 4mm multicores for high power & line array systems 18 core multicores suitable for lighting use Application notes Wide range of conductor counts & sizes Reduced OD 2 x 2.5mm will t XLR connectors and mono jacks Multicore construction optimised for dynamic use Ultra pure oxygen free copper for outstanding sonic integrityblack speaker series Overall Mechanical specication Conductor Bare ultra pure oxygen free copper Insulation PVC Overall jacket Flexible PVC composite matt black RAL 9005 Working voltage 300/500V Test voltage 2000V DC 1 minute Characteristics by stock code 2 Conductor (twin-axial) cables Stock code Description Overall diameter Weight Kg/km Conductor stranding Conductor resistance Ohm/Km 268-515-000 2 x 1.50mm twin-axial 6.50mm 78 30 x 0.25mm 12.30 268-525-000 2 x 2.50mm twin-axial 7.60mm 122 50 x 0.25mm 7.65 268-545-000 2 x 4.00mm twin-axial 11.00mm 162 50 x 0.30mm 4.50 268-526-000 2 x 6.00mm twin-axial 14.00mm 250 84 x 0.30mm 3.10 Multicore cables 268-542-000 4 x 2.50mm multicore 10.25mm 160 50 x 0.25mm 7.65 268-562-000 6 x 2.50mm multicore 11.60mm 250 50 x 0.25mm 7.65 268-582-000 8 x 2.50mm multicore 15.80mm 350 50 x 0.25mm 7.65 268-544-000 4 x 4.00mm multicore 12.20mm 260 127 x 0.20mm 4.60 268-584-000 8 x 4.00mm multicore 17.70mm 500 127 x 0.20mm 4.60 268-515-018 18 x 1.50mm multicore 14.50mm 450 30 x 0.25mm 12.30 268-525-018 18 x 2.50mm multicore 18.00mm 700 50 x 0.25mm 7.65 268-545-016 16 x 4.00mm multicore TBC 1000 127 x 0.20mm 4.60 2 to 8 conductor colour codes 18 conductor colour codes Conductor 1 Red Conductor 1 Red Conductor 10 Orange Conductor 2 Blue Conductor 2 Grey Conductor 11 Pink Conductor 3 Green Conductor 3 Brown Conductor 12 Purple Conductor 4 Yellow Conductor 4 Blue Conductor 13 Red/white Conductor 5 White Conductor 5 Black Conductor 14 Purple/White Conductor 6 Black Conductor 6 White Conductor 15 Black/White Conductor 7 Brown Conductor 7 Green/Yellow Conductor 16 Blue/White Conductor 8 Violet Conductor 8 Cream Conductor 17 Brown/White Conductor 9 Clear Conductor 18 Grey/White Maximum reel length 500 metres
