Product Information

56456 302 012

56456 302 012 electronic component of Varta

Datasheet
LI-ION/LI-POL BATTERY, 3.7V, 2.4AH
Manufacturer: Varta
This product is classified as Large/Heavy, additional shipping charges may apply. A customer service representative may contact you after ordering to confirm exact shipping charges



Price (USD)
N/A

Shipping Restricted

Read More Specifications


Manufacturer
Product Category
Battery Technology
Battery Capacity
Battery Voltage
Battery Size Code
Battery Terminals
External Diameter
External Height
External Width
External Depth
Weight
Battery Iec Code
Battery Neda Code
Product Range
Approvals Standards
Dc / Dc Converter Output Type
No Of Outputs
Output Current Max
Output Power Max
Output Voltage Nom
LoadingGif

Notes:- Show Stocked Products With Similar Attributes.

More Products By Manufacturer "Varta"

Image Description
6016 101 401 electronic component of Varta 6016 101 401

Battery: lithium; 3V; CR2016; Batt.no:1; Ø20x1.6mm
Stock : 0

6016 101 501 electronic component of Varta 6016 101 501

Battery: lithium; 3V; CR2016; Ø20x1.6mm; 90mAh; non-rechargeable
Stock : 0

56456 701 099 electronic component of Varta 56456 701 099

BATTERY, LI-ION/LI-POL, 3.7V, 1.2AH
Stock : 0

56457 201 012 electronic component of Varta 56457 201 012

LI-ION/LI-POL BATTERY, 3.7V, 1AH
Stock : 0

6016401501 electronic component of Varta 6016401501

BATTERY, LITHIUM, CR2016H
Stock : 0

6016201501 electronic component of Varta 6016201501

BATTERY, LITHIUM, CR2016V
Stock : 0

56456 702 099 electronic component of Varta 56456 702 099

BATTERY, LI-ION/LI-POL, 3.7V, 2.4AH
Stock : 0

56 703 101 404 electronic component of Varta 56 703 101 404

Re-battery: Ni-MH; AAA, R3; 1.2V; 800mAh; LONGLIFE; Package: blister
Stock : 0

56 706 101 404 electronic component of Varta 56 706 101 404

Re-battery: Ni-MH; AA; 1.2V; 2100mAh; LONGLIFE; Package: blister
Stock : 0

5 716 101 402 electronic component of Varta 5 716 101 402

Re-battery: Ni-MH; AA; 1.2V; 2600mAh; Package: blister; Batt.no:2
Stock : 0

More Products By Category "Unclassified"

Image Description
05328 electronic component of Greenlee 05328

Punches & Dies PLUG REPLACEMENT (G2090)
Stock : 0

56456 701 099 electronic component of Varta 56456 701 099

BATTERY, LI-ION/LI-POL, 3.7V, 1.2AH
Stock : 0

56457 201 012 electronic component of Varta 56457 201 012

LI-ION/LI-POL BATTERY, 3.7V, 1AH
Stock : 0

84688-104LF electronic component of Amphenol 84688-104LF

Conn Hard Metric RCP 180 POS 2mm Press Fit RA Thru-Hole Tube
Stock : 229

3296X-1-502RLF electronic component of Bourns 3296X-1-502RLF

Res Cermet Trimmer 5K Ohm 10% 0.5W(1/2W) 25(Elec)Turn 2.19mm (11.05 X 4.83 X 10.03mm) Pin Thru-Hole T/R
Stock : 943

18.038 electronic component of Apem 18.038

LEGEND, "RESET"
Stock : 0

05.33.212 electronic component of Ettinger 05.33.212

STANDOFF, ROUND FEMALE, NYLON, 12MM, M3
Stock : 0

194A307 electronic component of Seaward 194A307

LABEL, BARCODE SERIAL NO.
Stock : 0

05.33.220 electronic component of Ettinger 05.33.220

STANDOFF, ROUND FEMALE, NYLON, 20MM, M3
Stock : 0

HMCP150T4C electronic component of Eaton HMCP150T4C

CIRCUIT BREAKER, 3 POLE, 150A
Stock : 2

Additional Infomation About Product

Product Information 2P/LPP 503562 S PCM WC VKB 56456 302 012 MM month two digits Y year one digit R week one digit Circuit Diagram 1. GENERAL Battery Pack including safety circuit & wires with connector Cell LPP 503562 S PCM Y es NTC 10 k 1% B - va l u e 3 4 3 5 K 1% ID None C o n fi g u r a t i o n 2P stack up Weight a ppr. 45g 2. ELECTRICAL SPECIFICATION Rated Capacity 2300mAh min., 2400mAh nominal Nominal Voltage 3 .7V Watt-Hour Rating 8 .9Wh Charging Method Constant Current + Constant Voltage Max. Charge Voltage: 4.2V Max. Continuous Charge Current: 1150mA (limited by cell DS) Rec. Charge Cut Off: 23mA or timer 3.5h Max. Continuous Discharge Current: 2000mA (limited by connector) Rec. Discharge Cut Off: 3 V Internal Impedance: a p p r ox . 9 0 m Expected Cycle Life (1.0C/1.0C) 23.5C 500 cycles > 70 % CELL PROTECTION Overcharge Detection 4 . 3V 2 0 mV (0 . 8 t o 1. 2 s e c . d e l ay, r e s u m e 4 .1V 3 0 mV ) Overdischarge Detection: 2 . 4V 3 5 mV ( 76 . 8 t o 115 . 2 m s e c . d e l ay, remove loader & charging current) Overcurrent Detection 3.2A to 5.2A (9.6 to 14.4msec. delay discharge) 3. AMBIENT CONDITIONS Temperature Range C h a r g e 0 to +45C D i s c h a r g e -20 to +60C S t o r a g e w i t h > 8 0 % capacity recovery 1 y ear at -20 to +30C 3 months at -20 to +45C 1 m onth at -20 to +60C H u m i d i t y 65 20%RH 4. ENVIRONMENTAL AND SAFETY Please follow VARTA Handling and Safety Precautions for LiIon & LiPolymer. T h e c e l l u s e d i s a U L r e c o g n i z e d c o m p o n e n t a c c o r d i n g t o U L16 42 a n d U N 3 8 . 3 c e r t i fi e d . T h e c e l l i s I EC 6 213 3 e d i t i o n 2 c e r t i fi e d . This battery meets the requirements of Battery Directives and the battery parts are RoHS-Compliant. Minimum Order Quantity: 600 pcs / Order Multiples: 120 pcs - Product for OEM customers only VARTA Storage GmbH - Rev No. 4 0815 715415 1 00 STFX-ON Electronics Largest Supplier of Electrical and Electronic Components Click to view similar products for varta manufacturer: Other Similar products are found below : 56456 702 099 18750 4114 210 501 4610 726 406 4122 210 511 LCD-CHARGER + 4XAA 2400MAH 449915B 4607 726 406 55171403014 55625603059 55615602940 4112101411 4 022 211 111 4 106 101 436 4 020 211 111 MINI CHARGER + 2XAA 2100MAH MINI-CHARGER 17730 LCD-SMART-CHARGER 414086X POCKET-CHARGER + 4XAA 2100MAH 458980A LCD MULTI CHARGER CG511-150-PB EE UNIVERSAL CHARGER CG401D-050-PB CG511-050-PB CU303-018-PB 413675G CG381D-G-100-PB CU202-030-PB 55615603059 CG381D-G-150-PB CG481G-050-PB CU303-030-PB CG511D-030-PB CA317-PB CU201G-B-030-PB 095668F 4600 726 406 CA418-PB CG481G-030-PB CG511D-100-PB CG511-030-PB CG511D-150-PB CG381D-G-050-PB CU302-030- PB CG341-030-PB CU201G-B-050-PB CA089-PB
