333 3 293D www.vishay.com Vishay Sprague Solid Tantalum Surface Mount Chip Capacitors TANTAMOUNT, Molded Case, Standard Industrial Grade FEATURES Molded case available in six case codes Terminations: 100 % matte tin standard, Available tin / lead available Available Compatible with high volume automatic pick and place equipment Meets EIA-535-BAAC mechanical and performance requirements Available Qualified to EIA-717 LINKS TO ADDITIONAL RESOURCES Moisture sensitivity level 1 T Optical character recognition qualified 3D Models Calculators Related Did You Technical Compliant terminations Documents Know Notes Material categorization: for definitions of compliance PERFORMANCE / ELECTRICAL please see www.vishay.com/doc 99912 CHARACTERISTICS Note * This datasheet provides information about parts that are www.vishay.com/doc 40192 RoHS-compliant and / or parts that are non RoHS-compliant. For Operating Temperature: -55 C to +125 C example, parts with lead (Pb) terminations are not RoHS-compliant. Please see the information / tables in this datasheet for details (above 85 C, voltage derating is required) Capacitance Range: 0.10 F to 1000 F APPLICATIONS Capacitance Tolerance: 5 %, 10 % , 20 % Industrial 100 % Surge Current Tested (D and E Case Codes) Telecom infrastructure Voltage Rating: 4 V to 75 V DC DC General purpose Note For recommended voltage derating guidelines see Typica l Performance Characteristics ORDERING INFORMATION 293D 107 X9 010 D 2WE3 TYPE CAPACITANCE CAPACITANCE DC VOLTAGE RATING CASE CODE TERMINATION AND TOLERANCE AT +85 C PACKAGING This is expressed in X0 = 20 % This is expressed in V. See Ratings Matte tin picofarads. The first X9 = 10 % To complete the three-digit and Case 2TE3 = 7 (178 mm) reel two digits are the X5 = 5 % block, zeros precede the Codes table 2WE3 = 13 (330 mm) reel significant figures. (special order) voltage rating. A decimal 2DE3 = 7 (178 mm) reel, The third is the number point is indicated by an R dry pack of zeros to follow. (6R3 = 6.3 V). 2RE3 = 13 (330 mm) reel, dry pack Tin / lead 8T = 7 (178 mm) reel 8W = 13 (330 mm) reel 8D = 7 (178 mm) reel, dry pack 8R = 13 (330 mm) reel, dry pack Notes We reserve the right to supply higher voltage ratings and tighter capacitance tolerance capacitors in the same case size. Voltage substitutions will be marked with the higher voltage rating We reserve the right to supply better series with more extensive screening Dry pack as specified in J-STD-033 Revision: 30-Mar-2020 Document Number: 40002 1 For technical questions, contact: tantalum vishay.com THIS DOCUMENT IS SUBJECT TO CHANGE WITHOUT NOTICE. THE PRODUCTS DESCRIBED HEREIN AND THIS DOCUMENT ARE SUBJECT TO SPECIFIC DISCLAIMERS, SET FORTH AT www.vishay.com/doc 91000 DDD D 293D www.vishay.com Vishay Sprague DIMENSIONS in inches millimeters L W T W H T (MIN.) Glue Pad H Glue Pad P CASE CODE EIA SIZE L W H P T T (MIN.) W H 0.126 0.008 0.063 0.008 0.063 0.008 0.031 0.012 0.047 0.004 0.028 A 3216-18 3.2 0.20 1.6 0.20 1.6 0.20 0.80 0.30 1.2 0.10 0.70 0.138 0.008 0.110 0.008 0.075 0.008 0.031 0.012 0.087 0.004 0.028 B 3528-21 3.5 0.20 2.8 0.20 1.9 0.20 0.80 0.30 2.2 0.10 0.70 0.236 0.012 0.126 0.012 0.098 0.012 0.051 0.012 0.087 0.004 0.039 C 6032-28 6.0 0.30 3.2 0.30 2.5 0.30 1.3 0.30 2.2 0.10 1.0 0.287 0.012 0.169 0.012 0.110 0.012 0.051 0.012 0.094 0.004 0.039 D 7343-31 7.3 0.30 4.3 0.30 2.8 0.30 1.3 0.30 2.4 0.10 1.0 0.287 0.012 0.169 0.012 0.157 0.012 0.051 0.012 0.094 0.004 0.039 E 7343-43 7.3 0.30 4.3 0.30 4.0 0.30 1.3 0.30 2.4 0.10 1.0 Note Glue pad (non-conductive, part of molded case) is dedicated for glue attachment (as user option) RATINGS AND CASE CODES F 4 V 6.3 V 10 V 16 V 20 V 25 V 35 V 50 V 63 V 75 V 0.10 AA A A 0.15 AA / B B 0.22 AA / B B 0.33 AA A / B B 0.47 A A A A / B A / B / C B 0.68 A A A A / B B / C B / C 1.0 A A A / B A / B A / B B / C D 1.5 A A A / B A / B A / B B / C B / C / D B / C / D 2.2 A A A / B A / B A / B A / B / C B / C B / C / D D 3.3 A A / B A / B A / B A / B / C A / B / C B / C / D C / D D D 4.7 A / B A / B A / B / C A / B / C A / B / C A / B / C / D B / C / D C / D / E D E 6.8 A / B A / B A / B / C A / B / C A / B / C B / C / D C / D D / E 10 A / B A / B / C A / B / C A / B / C / D B / C / D B / C / D C / D D / E E 15 A / B / C A / B / C A / B / C B / C B / C / D B / C / D C / D / E E 22 A / B / C A / B / C A / B / C / D B / C / D B / C / D C / D / E D / E 33 A / B / C A / B / C B / C / D B / C / D C / D D / E D / E (1) 47 A / B / C A / B / C / D B / C / D C / D / E D / E D / E E 68 B / C / D B / C / D B / C / D / E D / E D / E E 100 A / B / C / D B / C / D / E B / C / D / E D / E D / E 120 D D E 150 B / C / D C / D / E C / D / E D / E 220 B / C / D / E C / D / E D / E E 330 D / E D / E D / E 470 D / E D / E E 680 D / E E 1000 E E Note (1) 125 C life test post test limits per AEC-Q200 Revision: 30-Mar-2020 Document Number: 40002 2 For technical questions, contact: tantalum vishay.com THIS DOCUMENT IS SUBJECT TO CHANGE WITHOUT NOTICE. THE PRODUCTS DESCRIBED HEREIN AND THIS DOCUMENT ARE SUBJECT TO SPECIFIC DISCLAIMERS, SET FORTH AT www.vishay.com/doc 91000
