CTS1, CTS13, 749DX www.vishay.com Vishay Sprague Solid-Electrolyte TANTALEX Capacitors, Hermetically Sealed, Axial-Lead, CECC Approved FEATURES Terminations: tin / lead (SnPb), Available 100 % tin (RoHS-compliant) Hermetically sealed metal case with plastic film Available insulation Extended capacitance range (type 749DX) High operational stability with both time and temperature Low leakage current Low dissipation factor Material categorization: for definitions of compliance please see www.vishay.com/doc 99912 PERFORMANCE CHARACTERISTICS Note Operating Temperature: * This datasheet provides information about parts that are -55 C to +85 C (types CTS13) RoHS-compliant and / or parts that are non-RoHS-compliant. For -55 C to +125 C (types CTS1, 749DX) example, parts with lead (Pb) terminations are not RoHS-compliant. Please see the information / tables in this datasheet for details. SPECIFICATIONS CECC BS APPLICATIONS 30201-001 749DX 9073-N001749DX Performance and reliability has been proven in a wide range 30201-002 CTS1 of applications such as: filtering, by-pass, coupling, energy 30201-005 CTS13 storage, timing circuits. 30201-029 749DX ORDERING INFORMATION CTS13 105 X0 040 A 2 P E3 TYPE CAPACITANCE CAPACITANCE DC VOLTAGE RATING CASE STYLE PACKAGING RoHS- TOLERANCE AT +85 C CODE NUMBER COMPLIANT Identifies the basic Expressed in X0 = 20 % Expressed in volts. See 0 = bare See Tape E3 = 100 % tin capacitor design picofarads. X9 = 10 % Where necessary, Ratings case and Reel termination CTS1 = First two digits X5 = 5 % * zeros precede the and 2 = Packaging (RoHS-compliant) CECC 30201-002 are significant. * Special order voltage rating to Case plastic-film Blank = SnPb CTS13 = Third digit is the complete the Codes insulation termination CECC 30201-005 number of 3 digit block table. 749DX = zeros following. 6R3 = 6.3 V CECC 30201-001 / CECC 30201-029 DIMENSIONS in inches millimeters 1.500 0.250 1.500 0.250 D 38.10 6.35 38.10 6.35 dia. L Positive lead 1 + - 0.047 1.19 max. Solid tinned 0.125 3.18 max. J nickel leads max. LEAD DIAMETER CASE CODE L 0.031 0.79 J max. D max. 1 + 10 %, - 0.05 A 0.286 7.26 0.402 10.2 0.141 3.6 0.020 0.5 B 0.474 12.04 0.590 15.0 0.192 4.9 0.020 0.5 C 0.686 17.42 0.807 20.5 0.295 7.5 0.025 0.6 D 0.786 19.96 0.945 24.0 0.364 9.1 0.025 0.6 Revision: 04-Dec-14 Document Number: 42073 1 For technical questions, contact: tantalum vishay.com THIS DOCUMENT IS SUBJECT TO CHANGE WITHOUT NOTICE. THE PRODUCTS DESCRIBED HEREIN AND THIS DOCUMENT ARE SUBJECT TO SPECIFIC DISCLAIMERS, SET FORTH AT www.vishay.com/doc 91000 CTS1, CTS13, 749DX www.vishay.com Vishay Sprague RATINGS AND CASE CODES - TYPE CTS1 RATED VOLTAGE U (+85 C) R 6.3 V 10 V 16 V 25 V 40 V 50 V 63 V C R (F ) CATEGORY VOLTAGE U (+125 C) C 4 V 6.3 V 10 V 13 V 25 V 33 V 40 V 0.10 A 0.12 A 0.15 A 0.18 A 0.22 A 0.27 AA 0.33 AA 0.39 AA 0.47 AA A 0.56 AAA 0.68 AA A 0.82 AA B 1.0 AA B 1.2 AB B 1.5 ABBB 1.8 A BBB 2.2 A BBB 2.7 A BBB 3.3 A BBB 3.9 A BBB 4.7 A BBC 5.6 A B C C 6.8 A B C C 8.2 BCCC 10 BCCC 12 B CCD 15 B CCD 18 B CCD 22 B CD 27 B CD 33 B CD 39 B C D 47 B C D 56 B C D 68 CD 82 CD 100 CD 120 C D 150 C D 180 D 220 D 270 D 330 D Note Preferred ratings are in bold characters. Non-preferred ratings are available only with a capacitance tolerance of 10 % or 5 % (special order). Revision: 04-Dec-14 Document Number: 42073 2 For technical questions, contact: tantalum vishay.com THIS DOCUMENT IS SUBJECT TO CHANGE WITHOUT NOTICE. THE PRODUCTS DESCRIBED HEREIN AND THIS DOCUMENT ARE SUBJECT TO SPECIFIC DISCLAIMERS, SET FORTH AT www.vishay.com/doc 91000
