0603WAF470KT5E Thick Film Resistors - SMD by Uniroyal – Compact 47O Resistor for Surface-Mount Electronics
The Thick Film Resistors - SMD 0603WAF470KT5E by Uniroyal are compact and cost-efficient resistors designed to deliver stable resistance in space-constrained circuit designs. With a 47O resistance, ±1% tolerance, and standard 0603 footprint, these resistors are ideal for signal termination, voltage dividers, and general-purpose use in consumer electronics, automotive circuits, and industrial control units. This blog explores the full specifications, key features, applications, and how to source Thick Film Resistors - SMD by Uniroyal from Xon Electronics.
Technical Specifications of 0603WAF470KT5E
-
Manufacturer: Uniroyal
-
Part Number: 0603WAF470KT5E
-
Type: Thick Film Resistor – Surface Mount
-
Resistance: 47O
-
Tolerance: ±1%
-
Power Rating: 0.1W (1/10W)
-
Package Size: 0603 (1.6mm x 0.8mm)
-
Temperature Coefficient: ±100 ppm/°C
-
Operating Temperature: -55°C to +155°C
-
Mounting Type: Surface Mount Device (SMD)
-
Compliance: RoHS, Lead-Free
-
Category: Passive Components, SMD Resistors, Thick Film
The 0603WAF470KT5E Thick Film Resistors - SMD by Uniroyal are designed for excellent thermal stability and performance in automated circuit assemblies.
Key Features of 0603WAF470KT5E
-
47O Resistance ±1% – Ideal for signal integrity and impedance matching
-
Compact 0603 Package – Supports high-density SMD layouts
-
Stable Thick Film Composition – Maintains performance under varying conditions
-
Wide Operating Temp Range – From -55°C to +155°C for harsh environments
-
Automated Soldering Compatibility – Reflow and wave soldering supported
-
RoHS Compliant – Environmentally safe and lead-free
These attributes make Thick Film Resistors - SMD by Uniroyal highly suitable for both low- and high-volume manufacturing across electronics sectors.
Applications of 0603WAF470KT5E
The Thick Film Resistors - SMD by Uniroyal are found in various electronic assemblies, including:
Their reliability and compact form make them a perfect fit for modern, miniaturized PCBs.
Mounting and Soldering Overview
Mounting Style: Surface Mount
Soldering Methods: Compatible with reflow and wave soldering processes
Footprint: 0603 standard (JEDEC compliant)
Pad Compatibility: Fits standard 0603 solder pad layouts
The Thick Film Resistors - SMD by Uniroyal are optimized for fast, automated PCB production lines and precise electrical performance.
Use Case Scenario: Impedance Control in LED Driver Circuit
Scenario: An LED lighting manufacturer needed a compact resistor for current limiting in an LED driver PCB.
Problem: Overheating and inconsistent performance in cheaper resistor variants.
Solution: The 0603WAF470KT5E Thick Film Resistors - SMD by Uniroyal offered consistent 47O resistance and reliable thermal handling.
Result: Lower failure rates, consistent light output, and higher customer satisfaction.
This use case proves why Thick Film Resistors - SMD by Uniroyal are a trusted choice for thermal stability and performance.
Download Datasheet for 0603WAF470KT5E
Need full specs, graphs, or mechanical layout?
[Download 0603WAF470KT5E Datasheet from Xon Electronics]
Why Buy from Xon Electronics?
Choose Xon Electronics for original and certified Thick Film Resistors - SMD by Uniroyal:
- 100% Genuine Uniroyal Components
- Global Shipping – USA, India, Australia, Europe & more
- Bulk Order Discounts & OEM Supply
- Technical Support for Engineers
- Safe & Secure Online Ordering at www.xonelec.com
Conclusion
The 0603WAF470KT5E Thick Film Resistors - SMD by Uniroyal offer a balance of precision, compact size, and cost-efficiency for modern electronics. Whether you're designing lighting systems, handheld devices, or industrial PCBs, these resistors provide the stability and reliability your project demands. Available now at Xon Electronics with fast global delivery.
