08-52-0113 Headers & Wire Housings by Molex – Compact, Reliable PCB Connectivity

The Headers & Wire Housings 08-52-0113  by Molex are part of the trusted KK 254 series, designed for versatile board-to-board and wire-to-board connections. Known for their high mechanical reliability and ease of assembly, these single-row headers are ideal for compact electronic devices, industrial equipment, and consumer applications. With a standard 2.54mm pitch, the Headers & Wire Housings by Molex offer seamless integration into a wide range of PCB designs.

In this blog, we’ll explore the key specifications, core features, use cases, pinout configuration, and the advantages of sourcing from Xon Electronics with worldwide delivery.


?? Technical Specifications of 08-52-0113

  • Manufacturer: Molex

  • Part Number: 08-52-0113

  • Type: PCB Header

  • Series: KK 254

  • Pitch: 2.54mm

  • Mounting Style: Through-Hole

  • Termination Style: Solder

  • Number of Positions: 3

  • Contact Plating: Tin

  • Current Rating: 5.0A max

  • Operating Temperature Range: -40°C to +105°C

  • Category: Connectors, Headers, Wire Housings

These headers are perfect for signal and low-power connections in compact, modular circuit boards.


Key Features of 08-52-0113 Headers & Wire Housings

  • Standard 2.54mm Pitch – Compatible with industry-standard components

  • Durable Tin Plating – Ensures excellent electrical contact

  • High Current Capacity – Up to 5A for reliable power transfer

  • Through-Hole Mounting – Provides robust PCB anchoring

  • Mating Compatibility – Works with KK 254 crimp housings and connectors

These features make 08-52-0113 Headers & Wire Housings by Molex ideal for projects requiring flexible and reliable PCB interconnect solutions.


Applications of 08-52-0113 Headers & Wire Housings

The 08-52-0113 Headers & Wire Housings by Molex are used across various industries:

  • Industrial Control Systems

  • Consumer Electronics (TVs, Radios)

  • Power Supplies and LED Lighting

  • Test & Measurement Equipment

  • Robotics and Embedded Systems

Thanks to their universal footprint and durability, these Headers & Wire Housings by Molex ensure stable connections in demanding environments.


Pin Configuration & Connection Overview

Connection for the 3-position 08-52-0113 header is straightforward:

PCB Pins:

[Pin 1] — Signal/Power
[Pin 2] — Ground
[Pin 3] — Signal/Power

Designed to be paired with Molex crimp terminals and housings, the Headers & Wire Housings by Molex support safe and efficient connections.


Use Case Scenario: Industrial Sensor Module

Scenario: A control system integrator needed a reliable low-profile connector for modular sensor units.

Problem: Alternative headers failed during vibration and rework cycles.

Solution: The 08-52-0113 Headers & Wire Housings by Molex offered a secure fit and strong through-hole retention.

Result: Reduced maintenance costs, faster field service, and more reliable signal performance.


Download Datasheet for 08-52-0113

Looking for exact dimensions, current specs, or housing compatibility?

[Download the 08-52-0113 Datasheet from Xon Electronics]


Why Buy from Xon Electronics?

Xon Electronics offers genuine 08-52-0113 Headers & Wire Housings by Molex with:

  • Trusted Molex Stock
  • Global Delivery – USA, India, Australia, Europe & beyond
  • Bulk Supply for OEM and EMS Needs
  • Technical Support for Part Matching
  • Fast, Secure Online Ordering

Shop at www.xonelec.com and build your systems with trusted Headers & Wire Housings by Molex.


Conclusion

The 08-52-0113 Headers & Wire Housings by Molex are a proven solution for robust, compact PCB connectivity. With high current handling, standard pitch, and wide compatibility, they serve countless design needs across the electronics industry. Order today from Xon Electronics, with worldwide delivery to the USA, India, Australia, Europe, and more.


FAQs – 08-52-0113 Headers & Wire Housings by Molex

Q1. What is the pitch of this header?
It has a 2.54mm standard pitch.

Q2. How many positions does it support?
The 08-52-0113 model has 3 positions.

Q3. Is it suitable for power connections?
Yes, it supports up to 5.0A of current.

Q4. Can I use it with crimp housings?
Yes, it mates with Molex KK 254 wire housings.

Q5. Where can I buy it internationally?
From www.xonelec.com, shipping to USA, India, Australia, Europe, and other regions.
