1N5336B Zener Diodes by NTE – Precision 5.6V Regulation for Industrial and Consumer Electronics
The Zener Diodes 1N5336B by NTE are high-power, precision voltage-regulating components designed to maintain a stable 5.6V output across a variety of electrical loads. Whether you're working with power supplies, voltage references, or circuit protection systems, these zener diodes are ideal for maintaining voltage consistency and reducing failure rates due to overvoltage. Trusted in the industry, the 1N5336B Zener Diodes by NTE offer solid electrical characteristics, high thermal tolerance, and a durable through-hole package.
In this blog, we'll review specifications, key features, use cases, wiring method, and how to order these diodes from Xon Electronics with global availability.
Technical Specifications of 1N5336B
-
Manufacturer: NTE
-
Part Number: 1N5336B
-
Type: Zener Diode
-
Zener Voltage (Vz): 5.6V ±5%
-
Power Dissipation: 5 Watts
-
Maximum Zener Impedance: 5O @ 230mA
-
Reverse Leakage Current (IR): 5µA max @ 1V
-
Polarity: Unidirectional
-
Package Type: DO-201AE (Axial Lead)
-
Mounting Style: Through Hole
-
Operating Temp Range: -65°C to +200°C
-
Category: 1N5336B Zener Diodes by NTE
These diodes are known for their precise regulation and dependable performance in demanding electrical environments.
Key Features of 1N5336B by NTE
-
Accurate 5.6V Zener Voltage – Perfect for voltage stabilization and regulation
-
High Power Dissipation (5W) – Handles larger current loads without overheating
-
Reliable Through-Hole Package – Ideal for robust mechanical and thermal applications
-
Low Reverse Leakage – Minimizes power loss during standby or idle conditions
-
Wide Operating Temp Range – Suitable for industrial and outdoor applications
With these characteristics, the 1N5336B Zener Diodes by NTE are an excellent choice for engineers designing durable and efficient voltage regulation systems.
Applications of 1N5336B Zener Diodes
The 1N5336B Zener Diodes by NTE are widely used in:
-
Linear Power Supply Circuits
-
Voltage Reference Modules
-
Overvoltage Protection Systems
-
Battery Management Devices
-
DC-DC Converter Output Stabilization
-
Embedded Electronics and Control Panels
From industrial automation to embedded systems, these zener diodes offer reliability where consistent voltage is critical.
Wiring and Connection Overview
Wiring the 1N5336B is straightforward:
The axial DO-201AE package allows secure mounting in PCBs or terminal blocks for robust circuit integration.
Use Case Scenario: Battery-Powered Sensor Design
Scenario: A hardware startup was building a battery-powered environmental sensor requiring a precise and low-noise voltage reference.
Problem: Inconsistent voltage outputs caused inaccurate readings and shortened battery life.
Solution: The 1N5336B Zener Diodes by NTE provided a stable 5.6V reference with minimal thermal drift.
Result: Improved sensor accuracy, increased power efficiency, and longer product lifespan.
This case illustrates the importance of choosing the right zener diodes for stable voltage output in compact, low-power designs.
Download Datasheet for 1N5336B
Looking for detailed specs, thermal ratings, and electrical performance charts?
[Download 1N5336B Datasheet from Xon Electronics]
Why Buy from Xon Electronics?
Choose Xon Electronics for genuine 1N5336B Zener Diodes by NTE, offering:
- Authentic NTE Electronics Components
- Global Shipping – USA, India, Australia, Europe & more
- Volume Pricing for OEMs and Distributors
- Technical Support for Application Design
- Secure Online Ordering System
Shop top-grade circuit protection and voltage regulation components at www.xonelec.com.
Conclusion
The 1N5336B Zener Diodes by NTE are engineered for precision voltage regulation in a wide variety of industrial, commercial, and consumer electronics. With high power handling, low leakage, and strong thermal performance, they are the ideal choice for voltage-sensitive designs. Now available at Xon Electronics with global delivery to the USA, India, Australia, Europe, and more.
