3-390112-1 DIMM Connectors by TE Connectivity – Reliable Memory Connectivity Solutions
The DIMM Connectors 3-390112-1 by TE Connectivity are high-performance Connectors designed for secure and efficient memory module integration in various computing systems. These robust Memory Connectors ensure reliable connections for DDR memory modules, offering enhanced signal integrity and mechanical stability in critical applications.
This blog explores the technical specifications, key features, applications, and installation details of these premium Memory Socket Connectors, along with information on how to download the datasheet or purchase from Xon Electronics.
Technical Specifications of 3-390112-1
-
Manufacturer: TE Connectivity
-
Model: 3-390112-1
-
Type: DIMM Connectors
-
Number of Contacts: 168
-
Mounting Type: Through Hole
-
Pitch: 1.27mm
-
Operating Voltage: 30V
-
Current Rating: 0.5A
-
Operating Temperature: -55°C to +85°C
-
Category: Connectors, Memory Connectors, Memory Socket Connectors, DIMM Connectors
These DIMM Connectors are built to support stable and high-speed memory operations in industrial and commercial computing systems.
Key Features of 3-390112-1 DIMM Connectors
-
Compatible with DDR memory modules for versatile applications
-
Compact design ideal for space-constrained systems
-
Secure latching mechanism for vibration resistance
-
High-temperature tolerance for industrial environments
-
Part of TE’s trusted range of Memory Connectors and Memory Socket Connectors
The 3-390112-1 DIMM Connectors by TE Connectivity provide reliable memory module connections for demanding computing tasks.
Applications of 3-390112-1 DIMM Connectors
-
Server motherboards and industrial computers
-
Embedded systems and high-performance computing devices
-
Consumer electronics requiring robust memory integration
-
Networking equipment and telecom systems
-
OEM designs needing durable DIMM Connectors
These Connectors ensure secure and efficient memory installation across multiple industries.
Installation and Handling Overview
To install the 3-390112-1 DIMM Connector:
-
Mount securely on the PCB using through-hole soldering techniques.
-
Insert the memory module carefully into the connector at a slight angle.
-
Press down until the module clicks into place with the side latches engaged.
-
Verify mechanical stability and perform a memory test for successful installation.
These Memory Socket Connectors are engineered for long-term performance and repeated insertion cycles.
Use Case Scenario: Industrial Embedded Systems
Scenario: A manufacturer of industrial computers required durable DIMM Connectors for ruggedized environments.
Problem: Standard connectors failed under vibration and temperature fluctuations.
Solution: The 3-390112-1 DIMM Connectors by TE Connectivity offered secure latching and robust performance even in harsh conditions.
Result: Improved system uptime and reduced service requirements in embedded systems.
Download Datasheet for 3-390112-1
Looking for detailed technical specifications and layout drawings?
Download 3-390112-1 Datasheet from Xon Electronics
Why Buy from Xon Electronics?
Xon Electronics supplies authentic TE Connectivity DIMM Connectors with:
-
100% Genuine Products for Memory Applications
-
Fast Global Shipping to USA, India, Australia, Europe & more
-
OEM Discounts and Bulk Order Options Available
-
Technical Support for Seamless Memory Integration
-
Secure Online Ordering at www.xonelec.com
FAQs – 3-390112-1 DIMM Connectors by TE Connectivity
Q1. What type of memory modules are compatible?
This connector supports DDR memory modules.
Q2. Is it suitable for industrial computing systems?
Yes, it is designed for use in high-reliability embedded and industrial applications.
Q3. Can it withstand frequent module replacements?
Yes, it is engineered for high durability and repeated insertion cycles.
Q4. What mounting type does it use?
It uses through-hole mounting for secure PCB integration.
Q5. Can I order this globally?
Yes, Xon Electronics ships to USA, India, Australia, Europe & more.
Conclusion
The 3-390112-1 DIMM Connectors by TE Connectivity deliver reliable, secure, and high-performance memory module connectivity for industrial and commercial systems. As part of TE’s trusted Memory Connectors range, they ensure durability and superior signal integrity. Order today from Xon Electronics for fast worldwide delivery and expert support.
