CHAR-112A150H General Purpose Relays by Churod – Reliable Switching for Diverse Applications
The General Purpose Relays CHAR-112A150H by Churod are compact, high-capacity relays ideal for a wide array of applications ranging from industrial automation to household appliances. With a robust switching capacity of 30A and a compact form factor, these relays deliver excellent electrical performance in space-constrained designs. If you’re looking for high-quality and dependable general-purpose relays, the CHAR-112A150H stands out as a versatile solution.
In this blog, we’ll explore the key technical specifications, main features, typical applications, wiring setup, and where to buy or download the datasheet from Xon Electronics. Whether you're upgrading a control panel or designing a new embedded system, this Churod relay offers superior performance and value.
Technical Specifications of CHAR-112A150H
-
Manufacturer: Churod Electronics
-
Part Number: CHAR-112A150H
-
Type: General Purpose Relay
-
Coil Voltage: 12V DC
-
Contact Configuration: SPST-NO (1 Form A)
-
Contact Rating: 30A @ 277VAC / 30VDC
-
Dielectric Strength: 4000VAC (coil to contact)
-
Mounting Type: Through Hole
-
Insulation Resistance: 1000MO min. @ 500VDC
-
Dimensions: Approx. 29 x 12.7 x 20.5 mm
-
Category: Relays, General Purpose Relays
These robust relays are UL, cUL, and TUV certified, ensuring compliance with international standards and optimal performance in demanding applications.
Key Features of CHAR-112A150H Relay
-
High Current Capacity (30A) – Handles heavy loads with ease
-
Compact Form Factor – Ideal for dense PCB designs
-
Wide Coil Voltage Range – Supports 12V DC input
-
High Dielectric Strength – Ensures safety and insulation
-
UL & TUV Certified – Global compliance and reliability
These features make the CHAR-112A150H General Purpose Relays by Churod a trusted option for engineers and system integrators.
Applications of CHAR-112A150H
The CHAR-112A150H General Purpose Relays by Churod can be used across various sectors, including:
-
HVAC Systems and Thermostats
-
Industrial Control Panels
-
Domestic Appliances (Washing Machines, Ovens)
-
Lighting Control Systems
-
Motor Controls and Pumps
-
Power Distribution and Protection Units
Whether you're switching motors or controlling lighting, these relays provide reliable and stable performance across applications.
Wiring and Connection Overview
Typical connection setup for the CHAR-112A150H relay:
[Coil Input] — Apply 12V DC between coil terminals
[Contact Output] — SPST-NO: Load connected between COM and NO terminal
Thanks to its standard pin layout and through-hole design, installation is straightforward and soldering is easy during PCB assembly.
Use Case Scenario: Industrial Fan Controller
Scenario: An automation company needed a cost-effective yet robust relay for controlling high-current industrial fans.
Problem: Previous relays failed under surge current and ambient heat.
Solution: The CHAR-112A150H General Purpose Relays by Churod offered 30A capacity and thermal stability with UL-rated certification.
Result: Enhanced equipment uptime, fewer relay replacements, and better system reliability under industrial conditions.
