CPF06 – Compact D-Sub High Density Connector by ILME for Signal Applications
The D-Sub High Density Connectors CPF06 by ILME are reliable and compact connectors designed for transmitting analog or digital signals in densely wired systems. Part of ILME’s trusted CPF series, this 15-pin female connector offers rugged construction and high mating precision, making it ideal for industrial, instrumentation, automation, and communication systems where space-saving and signal integrity are critical.
In this blog, we’ll explore the specifications, top features, typical use cases, connection guide, and how to download the datasheet or purchase from Xon Electronics.
Technical Specifications of CPF06
-
Manufacturer: ILME
-
Part Number: CPF06
-
Type: D-Sub High Density Connector
-
Connector Gender: Female
-
Number of Contacts: 15
-
Mounting Type: Panel Mount
-
Termination Type: Solder or Crimp (dependent on variant)
-
Housing Material: Thermoplastic Insulated Housing with Metal Shell
-
Operating Voltage: 125V AC
-
Operating Temperature: -40°C to +105°C
-
Category: Connectors, D-Sub High Density Connectors by ILME
Compact and easy to install, the CPF06 D-Sub High Density Connectors by ILME ensure reliable, high-density signal transmission in compact control or electronic systems.
Key Features of CPF06
-
High-Density 15-Pin Layout – Supports multiple signal channels in a small footprint
-
Secure Metal Shell Construction – Provides EMI shielding and mechanical stability
-
Wide Operating Temperature Range – Suitable for harsh industrial environments
-
Panel Mount Design – Ensures firm and permanent mounting in enclosures
-
Versatile Contact Options – Available in crimp or solder types for installation flexibility
Thanks to these features, D-Sub High Density Connectors by ILME are a preferred choice for signal interfacing in control panels, test equipment, and industrial devices.
Applications of CPF06 Connector
-
Industrial Machine Control Panels
-
PLC and DCS Systems
-
Communication Interfaces (RS-232/422/485)
-
Test and Measurement Equipment
-
Embedded Systems and Automation Units
The CPF06 D-Sub High Density Connectors by ILME are widely used where compact and dependable multi-pin connections are essential for system performance and stability.
Connection & Installation Guide
Here’s how to install the CPF06 connector:
[Step 1] Prepare wires or cable as per the terminal type (crimp or solder).
[Step 2] Terminate wires into the contact pins.
[Step 3] Insert the connector into the panel cutout.
[Step 4] Secure using the mounting screws or hardware provided.
[Step 5] Connect to a mating male connector and test signal continuity.
Engineered for fast and safe integration, D-Sub High Density Connectors by ILME help simplify the wiring of compact electronic systems.
Use Case Scenario – Control Cabinet Signal Interface
Scenario: A system integrator was designing a compact control cabinet with multiple analog signal lines for sensors and actuators.
Problem: Traditional terminal blocks consumed too much panel space and were difficult to maintain.
Solution: The CPF06 connector allowed for 15 signal lines in one compact, shielded connector interface.
Result: Reduced wiring clutter, faster installation, and improved EMI protection.
This use case shows why D-Sub High Density Connectors by ILME are vital for space-sensitive and signal-critical environments.
Download Datasheet for CPF06
Need detailed dimensions, pin assignments, or compliance data?
[Download CPF06 Datasheet from Xon Electronics]
Why Buy from Xon Electronics?
Xon Electronics offers a wide range of D-Sub High Density Connectors by ILME, including the CPF06 model:
- 100% Genuine ILME Connectors
- Worldwide Delivery – USA, India, Australia, Europe & more
- In Stock with Fast Shipping Options
- Technical Support and Compatibility Advice
- Safe, Reliable, and Convenient Online Ordering
Order now at www.xonelec.com and experience high-performance connectivity from ILME.
Conclusion
The CPF06 D-Sub High Density Connectors by ILME combine durability, compactness, and excellent signal reliability for demanding industrial and electronic systems. Whether you're designing a new machine interface or upgrading a legacy control system, D-Sub High Density Connectors by ILME provide a clean, space-saving, and professional solution—now available globally through Xon Electronics.
FAQs – CPF06 ILME Connector
Q1. What is the pin count of the CPF06?
It is a 15-pin female connector.
Q2. Is it suitable for signal transmission?
Yes, ideal for both analog and digital low-voltage signals.
Q3. What mounting style is supported?
It supports panel mounting.
Q4. Are crimp and solder versions available?
Yes, ILME offers both termination types.
Q5. Where can I purchase it globally?
At www.xonelec.com with delivery to USA, India, Australia, Europe, and more.
