IE-SW-BL05-4TX-1SC Ethernet Modules by Weidmüller – Industrial-Grade Networking for Embedded Systems

The Ethernet Modules IE-SW-BL05-4TX-1SC by Weidmüller are compact, robust unmanaged switches built for reliable Ethernet communication in industrial and embedded environments. Designed with 4 RJ45 ports and 1 SC fiber port, this module enables fast and secure data transmission in harsh operating conditions. Whether you're developing remote monitoring systems or industrial controllers, these Ethernet Modules provide the backbone for high-uptime connectivity in modern Embedded Solutions.

In this blog, we’ll explore the technical specs, features, industrial applications, wiring overview, and how to source this model from Xon Electronics.

Technical Specifications of IE-SW-BL05-4TX-1SC

• Manufacturer: Weidmüller

• Part Number: IE-SW-BL05-4TX-1SC

• Category: Embedded Solutions, Ethernet & Communication Modules, Ethernet Modules

• Ports: 4 x 10/100 Mbps RJ45, 1 x 100 Mbps SC fiber

• Switch Type: Unmanaged

• Operating Voltage: 12–48V DC

• Operating Temperature: -10°C to +60°C

• Housing: IP30-rated metal enclosure

• Mounting: DIN rail

• Certifications: CE, RoHS, UL

• EMC Protection: Built-in surge and ESD protection

• LED Indicators: Link/activity per port

Ideal for applications requiring reliable, compact Ethernet Modules within resilient Embedded Solutions.

Key Features of IE-SW-BL05-4TX-1SC by Weidmüller

• Industrial-Grade Design – Operates reliably in harsh and vibration-prone environments

• Fiber Uplink Support – SC fiber uplink enables long-distance communication

• Compact DIN Rail Mounting – Saves space in control cabinets

• Plug-and-Play Operation – Unmanaged switch setup with no configuration required

• Surge & ESD Protection – Shields against electrical interference and spikes

These capabilities make this device an excellent choice for embedded systems relying on rugged Ethernet & Communication Modules.

Applications of IE-SW-BL05-4TX-1SC Ethernet Module

This model is used in a range of Embedded Solutions and industrial systems such as:

• Industrial Automation Networks

• Remote Monitoring and Control Systems

• Building Management and HVAC

• Energy Systems and Solar Inverters

• Transportation and Railway Systems

• Smart Infrastructure Projects

Reliable networking is essential in mission-critical Embedded Solutions, and these Ethernet Modules ensure high-speed, uninterrupted communication.

Wiring and Connection Overview

Setting up the IE-SW-BL05-4TX-1SC is straightforward and field-ready:

• Power Supply: Connect to 12–48V DC via terminal block

• RJ45 Ports: Connect up to 4 Ethernet-enabled devices (controllers, cameras, sensors)

• SC Fiber Port: Uplink to a remote network using multimode fiber

• DIN Rail Mounting: Clip directly onto standard 35mm DIN rails

• Status LEDs: Monitor connection and activity per port

This industrial switch is one of the most convenient and reliable Ethernet Modules for space-efficient Embedded Solutions.

Use Case Scenario: Smart Building Automation Network

Scenario: A smart building integrator needed a compact, reliable Ethernet switch for connecting HVAC controllers, lighting panels, and access systems on different floors.

Problem: Power constraints and long transmission distances complicated the network design.

Solution: The IE-SW-BL05-4TX-1SC Ethernet Modules by Weidmüller provided a hybrid copper and fiber solution with wide voltage tolerance and DIN rail mounting.

Result: Stable, secure network operation with reduced maintenance—achieved using compact, industrial-grade Ethernet & Communication Modules within modern Embedded Solutions.

Download Datasheet for IE-SW-BL05-4TX-1SC

Need pinout diagrams, installation instructions, or mechanical dimensions?

Download IE-SW-BL05-4TX-1SC Datasheet from Xon Electronics

Get everything you need to integrate this trusted Weidmüller module into your Ethernet Modules infrastructure.

Why Buy from Xon Electronics?

Xon Electronics provides reliable sourcing for Weidmüller Ethernet & Communication Modules and other Embedded Solutions, with:

• 100% Genuine Industrial-Grade Components
• Worldwide Shipping – USA, India, Australia, Europe & more
• OEM & Developer Bulk Order Support
• Technical Support for Integration
• Secure Checkout and Fast Dispatch

Visit www.xonelec.com to upgrade your system with proven Ethernet Modules from Weidmüller.

Conclusion

The IE-SW-BL05-4TX-1SC Ethernet Modules by Weidmüller are built for demanding industrial environments, offering compact design, fiber connectivity, and high-performance switching. These modules are perfect for embedded and automation engineers looking for resilient, plug-and-play networking solutions.

Now available at Xon Electronics—your global partner for Ethernet & Communication Modules, rugged Embedded Solutions, and industrial-grade Ethernet Modules.
