MOC3023SM Triac & SCR Output Optocouplers by Isocom – High-Performance Isolation for AC Load Switching
The Triac & SCR Output Optocouplers MOC3023SM by Isocom are compact, surface-mount devices that provide robust electrical isolation and safe control of AC loads using low-voltage logic inputs. With excellent switching characteristics and high isolation voltage, these optoelectronics components are ideal for smart appliances, industrial automation, and power control systems. Known for quality and consistency, Triac & SCR Output Optocouplers by Isocom deliver reliable performance in demanding environments.
In this article, we cover technical specifications, features, use cases, and global ordering information for the MOC3023SM Triac & SCR Output Optocouplers by Isocom, available through Xon Electronics.
Technical Specifications of MOC3023SM
-
Manufacturer: Isocom
-
Part Number: MOC3023SM
-
Category: Optoelectronics, Optocouplers / Photocouplers
-
Input Side: Infrared LED
-
Output Side: Phototriac driver
-
Isolation Voltage: 5,300Vrms
-
Trigger Current (IFT): = 5mA
-
Voltage Range (AC Load): 110V–240V
-
Package: 6-pin SMD
-
Mounting Style: Surface Mount (SMD)
-
Series: Triac & SCR Output Optocouplers by Isocom
The Triac & SCR Output Optocouplers by Isocom are designed for precise, low-noise switching and are compatible with most microcontroller systems.
Key Features of MOC3023SM
-
High Isolation (5300Vrms) – Safeguards low-voltage control systems
-
Low Trigger Current (=5mA) – Works well with logic-level control
-
Zero-Crossing Free Design – Suitable for dimming and phase control applications
-
Compact SMD Package – Saves space in densely packed PCBs
-
Long-Term Reliability – No mechanical wear and high switching endurance
These benefits make the MOC3023SM Triac & SCR Output Optocouplers by Isocom an excellent choice for engineers designing safe and efficient AC switching systems.
Applications of MOC3023SM
The Triac & SCR Output Optocouplers by Isocom are widely used in:
-
Light Dimming Circuits
-
Smart Home Appliance Control
-
Solid-State Relays
-
HVAC and AC Fan Speed Controllers
-
Industrial Equipment Power Management
-
PLC Output Interfaces
These optocouplers / photocouplers ensure safe and isolated operation, protecting microcontrollers and logic devices from AC voltage spikes and surges.
Wiring Overview
-
Input (LED side): Connect to a digital control signal from microcontroller or logic device
-
Output (triac side): Gate signal drives external triac for AC load switching
-
Isolation Barrier: 5300Vrms to protect control circuit from high voltage
Thanks to its surface-mount design, the MOC3023SM is perfect for compact circuit boards in modern electronic systems.
Use Case Scenario: Embedded AC Fan Speed Controller
Scenario: A design engineer building an HVAC control system needed compact, isolated switching for 230V AC fan motors.
Problem: Electromechanical relays caused noise and frequent maintenance.
Solution: The MOC3023SM Triac & SCR Output Optocouplers by Isocom enabled silent, reliable switching with superior isolation and SMD convenience.
Result: Reduced circuit size, longer component life, and more stable fan speed control.
This illustrates how Triac & SCR Output Optocouplers by Isocom simplify and improve high-voltage switching in embedded systems.
