PS2502-4-A Transistor Output Optocouplers by CEL – Reliable Isolation for Optoelectronics Applications
The Transistor Output Optocouplers PS2502-4-A by CEL are designed to provide high-performance electrical isolation in various Optoelectronics applications. Featuring four independent channels, high isolation voltage, and Darlington output, these Optocouplers / Photocouplers ensure efficient signal transmission while protecting sensitive circuits from electrical noise. Whether used in industrial automation, power supplies, or communication systems, the PS2502-4-A is a trusted choice among Transistor Output Optocouplers.
1. Technical Specifications of PS2502-4-A
Understanding the technical details of the PS2502-4-A Transistor Output Optocouplers is essential for selecting the right component for your Optoelectronics applications. Below are the key specifications:
- Manufacturer: CEL (Renesas Electronics)
- Series: NEPOC
- Number of Channels: 4
- Isolation Voltage: 5000Vrms
- Current Transfer Ratio (Min): 200% @ 1mA
- Output Type: Darlington
- Maximum Output Voltage: 40V
- Maximum Output Current: 160mA
- Forward Voltage: 1.17V (typical)
- Rise/Fall Time: 100µs / 100µs
- Mounting Type: Through-hole
- Package: 16-DIP
These specifications highlight the module’s efficiency in providing electrical isolation while ensuring compatibility with various Optocouplers / Photocouplers for enhanced protection.
2. Key Features of PS2502-4-A
The PS2502-4-A Transistor Output Optocouplers offer several advanced features that make them a preferred choice for engineers:
- High Isolation Voltage: Provides 5000Vrms isolation, ensuring safe signal transmission in Optoelectronics applications.
- Darlington Output: Enhances current transfer ratio, making it ideal for Transistor Output Optocouplers used in high-gain circuits.
- Multi-Channel Design: Four independent channels allow simultaneous isolation of multiple signals.
- Low Power Consumption: Operates efficiently with minimal energy loss.
- Reliable Performance: Designed for industrial automation, power supplies, and communication systems.
These features demonstrate why the PS2502-4-A Transistor Output Optocouplers are a trusted solution for electrical isolation in various industries.
3. Applications of PS2502-4-A
The PS2502-4-A Transistor Output Optocouplers are widely used in various industries due to their robust design and reliable performance. Common applications include:
- Industrial Automation: Provides electrical isolation for control systems and sensors.
- Power Supplies: Ensures safe signal transmission in high-voltage circuits.
- Communication Systems: Protects data transmission lines from electrical interference.
- Medical Equipment: Used in diagnostic devices requiring high isolation.
- Consumer Electronics: Enhances circuit protection in smart home devices.
These applications highlight the versatility of the PS2502-4-A Transistor Output Optocouplers, making them a valuable component in modern Optoelectronics.
4. Circuit Diagram for PS2502-4-A Integration
Below is a basic schematic demonstrating how the PS2502-4-A Transistor Output Optocouplers can be used in an isolated signal transmission circuit:
Microcontroller Unit:
+Vcc —— [PS2502-4-A] —— Ground
This simple diagram illustrates the role of the optocoupler in ensuring efficient signal isolation, a critical aspect of Optocouplers / Photocouplers integration.
5. Use Case Scenario: Electrical Isolation in Industrial Automation
Imagine an industrial automation system where electrical isolation is crucial for preventing signal interference. The PS2502-4-A Transistor Output Optocouplers are deployed to ensure reliable signal transmission:
- Industry: Manufacturing
- Objective: Provide electrical isolation for control signals.
- Implementation:
- The optocoupler is integrated into the control circuit.
- Its 5000Vrms isolation ensures safe signal transmission.
- The Darlington output enhances current transfer ratio for improved performance.
- Outcome:
- Increased system reliability and reduced electrical noise.
- Enhanced durability and protection through Optoelectronics integration.
This use case demonstrates the value of the PS2502-4-A Transistor Output Optocouplers in industrial applications.
6. How to Download the PS2502-4-A Datasheet?
For detailed technical information, download the official datasheet for the PS2502-4-A Transistor Output Optocouplers from CEL’s website or authorized distributors. The datasheet provides in-depth details about electrical ratings, dimensions, and application guidelines.
7. Why Buy PS2502-4-A Transistor Output Optocouplers from Xon Electronics?
Xon Electronics is a trusted supplier of industrial components worldwide. Here’s why customers prefer Xon Electronics:
- Authenticity Guaranteed: Genuine CEL products for reliable performance.
- Competitive Pricing: Affordable rates for Optocouplers / Photocouplers and other components.
- Worldwide Shipping: Fast delivery across the USA, India, Australia, Europe, and beyond.
- Technical Support: Expert guidance for installation and troubleshooting.
- Secure Payments: Safe and easy online transactions.
For inquiries, bulk orders, or technical assistance, contact Xon Electronics today!
Conclusion
The PS2502-4-A Transistor Output Optocouplers by CEL are a high-performance solution for electrical isolation in electronic systems. With their advanced features, versatile applications, and global reliability, they stand out among Optocouplers / Photocouplers. Whether you’re working on industrial automation, power supplies, or communication systems, these optocouplers ensure optimal performance and durability. Trust Xon Electronics for genuine products, competitive pricing, and fast delivery.
