PS2561L-1-A Transistor Output Optocouplers by Renesas – High Reliability for Signal Isolation
The Transistor Output Optocouplers PS2561L-1-A by Renesas are advanced Optoelectronics components designed to deliver high performance, strong isolation, and reliable signal transmission. Engineered for durability and precision, these Transistor Output Optocouplers are used in various industrial, power, and communication applications.
In this article, we’ll cover the technical specifications, key features, and benefits of using these Optocouplers / Photocouplers in modern electronic systems.
Introduction
Renesas’ PS2561L-1-A Transistor Output Optocouplers are compact, high-speed isolation devices featuring a GaAs infrared LED and a high-gain phototransistor. These Optoelectronics components provide electrical isolation and noise immunity between circuits, making them ideal for switching, control, and logic interface designs.
Technical Specifications of PS2561L-1-A Transistor Output Optocouplers
-
Manufacturer: Renesas
-
Part Number: PS2561L-1-A
-
Type: Transistor Output Optocoupler
-
Input Type: GaAs Infrared LED
-
Output Type: NPN Phototransistor
-
Isolation Voltage: 3750 Vrms
-
Current Transfer Ratio (CTR): 80% – 160% (at IF = 5mA, VCE = 5V)
-
Collector-Emitter Voltage (VCEO): 80V
-
Collector Current (IC): 50mA
-
Package Type: 4-Pin LSOP (Low Profile)
-
Operating Temperature Range: -55°C to +110°C
-
Category: Optoelectronics, Optocouplers / Photocouplers, Transistor Output Optocouplers
Compact and efficient, the PS2561L-1-A delivers consistent signal integrity with low power consumption and high electrical isolation.
Key Features of PS2561L-1-A Transistor Output Optocouplers
-
High Isolation Voltage (3750 Vrms) – Protects control circuits from high-voltage transients.
-
High CTR Stability – Ensures consistent signal transmission performance.
-
Compact LSOP Package – Saves space in dense PCB layouts.
-
High-Speed Switching – Suitable for logic interfacing and feedback circuits.
-
Wide Temperature Range – Reliable operation in industrial and consumer environments.
These features make the PS2561L-1-A Transistor Output Optocouplers one of the most trusted Optoelectronics solutions for signal isolation and data transmission.
Applications of PS2561L-1-A Transistor Output Optocouplers
The PS2561L-1-A Transistor Output Optocouplers by Renesas are ideal for systems that require reliable electrical isolation and signal integrity, including:
-
Power Supply Feedback Circuits
-
Industrial Control Systems
-
Signal Isolation Interfaces
-
Communication Equipment
-
Consumer and Office Electronics
Datasheet
These Optocouplers / Photocouplers ensure stable operation and protection across both high- and low-voltage domains.
Use Case Scenario: Power Supply Feedback Loop
Scenario
A power supply designer required efficient Transistor Output Optocouplers for stable feedback isolation in a switching converter.
Problem
Conventional components introduced signal distortion and instability at higher switching speeds.
Solution
The PS2561L-1-A Optocouplers by Renesas offered fast switching, high isolation, and stable CTR, ensuring accurate voltage feedback.
Result
Improved feedback precision, lower noise interference, and enhanced power efficiency.
