PS2701A-1-F3-A Transistor Output Optocouplers by Renesas – Reliable Optical Isolation for Modern Electronics
The Transistor Output Optocouplers PS2701A-1-F3-A by Renesas are high-performance Optoelectronics components designed to provide efficient signal isolation between control and load circuits. Featuring a compact 4-pin package, these Transistor Output Optocouplers ensure safe and stable operation across a wide range of electronic applications.
In this blog, we’ll explore their technical specifications, features, and key advantages — and why engineers choose these Optocouplers / Photocouplers for reliable performance and durability.
Introduction
Renesas’ PS2701A-1-F3-A Transistor Output Optocouplers are designed for applications that demand high-speed and stable signal transmission with electrical isolation. These Optoelectronics devices feature a gallium arsenide (GaAs) infrared LED coupled with a silicon phototransistor, offering excellent linearity and response time.
Technical Specifications of PS2701A-1-F3-A Transistor Output Optocouplers
-
Manufacturer: Renesas
-
Part Number: PS2701A-1-F3-A
-
Type: Transistor Output Optocoupler
-
Input Type: GaAs Infrared LED
-
Output Type: NPN Phototransistor
-
Isolation Voltage: 5000 Vrms
-
Current Transfer Ratio (CTR): 80–160% (at IF = 5mA, VCE = 5V)
-
Collector-Emitter Voltage (VCEO): 80V
-
Operating Temperature Range: -55°C to +100°C
-
Package Type: 4-Pin DIP
-
Category: Optoelectronics, Optocouplers / Photocouplers, Transistor Output Optocouplers
The PS2701A-1-F3-A ensures reliable signal integrity and electrical isolation, making it suitable for both digital and analog signal interfacing.
Key Features of PS2701A-1-F3-A Transistor Output Optocouplers
-
High Isolation Voltage (5000 Vrms) – Ensures electrical safety and noise immunity.
-
High CTR and Linearity – Delivers stable and accurate signal transmission.
-
Compact DIP Package – Fits easily into PCBs with limited space.
-
Wide Operating Temperature Range – Performs reliably in harsh environments.
-
Long Lifespan and High Reliability – Suitable for industrial-grade use.
These features make the PS2701A-1-F3-A Transistor Output Optocouplers one of the most trusted Optoelectronics components in automation and control systems.
Applications of PS2701A-1-F3-A Transistor Output Optocouplers
The PS2701A-1-F3-A Transistor Output Optocouplers by Renesas are widely used in electronic systems that require isolation between input and output signals, including:
-
Switching Power Supplies
-
Microprocessor Input/Output Isolation
-
Industrial Automation and Control Systems
-
Communication and Signal Interfaces
-
Home Appliances and Consumer Electronics
Datasheet
These Optocouplers / Photocouplers are ideal for protecting sensitive components and ensuring stable, interference-free communication.
Use Case Scenario: Microcontroller Signal Isolation
Scenario
An industrial control system required reliable Transistor Output Optocouplers for isolating microcontroller signals from high-voltage control circuits.
Problem
Conventional devices suffered from noise interference and inconsistent CTR.
Solution
The PS2701A-1-F3-A Optocouplers by Renesas provided superior noise immunity, consistent CTR, and stable switching characteristics.
Result
Enhanced circuit reliability, safer system design, and improved long-term stability in industrial environments.
