SMBJ15CA ESD Suppressors by Juxing – Superior Circuit Protection for Modern Electronics

The ESD Suppressors/TVS Diodes SMBJ15CA by Juxing Electronic Technology are high-performance bidirectional diodes designed to protect sensitive circuits from electrostatic discharge (ESD) and transient voltage surges. With a compact DO-214AA (SMB) footprint and robust 600W peak power handling, these devices are essential for any application requiring fast, efficient, and compact circuit protection.

In this blog, we’ll explore specifications, features, applications, wiring diagrams, use cases, and how to order online from Xon Electronics with global delivery to the USA, India, Australia, Europe, and other countries.

1. Technical Specifications of SMBJ15CA

• Manufacturer: Juxing Electronic Technology

• Part Number: SMBJ15CA

• Type: ESD Suppressors/TVS Diodes

• Polarity: Bidirectional

• Stand-off Voltage: 15V

• Breakdown Voltage: 16.7V (typical)

• Clamping Voltage: 24.4V at 25A

• Peak Pulse Power: 600W (10/1000µs waveform)

• Peak Pulse Current: 25A

• Package Type: DO-214AA (SMB)

• Category: Circuit Protection, ESD Suppressors/TVS Diodes

Built to meet international safety standards, the SMBJ15CA delivers consistent protection in harsh electrical environments.

2. Key Features of SMBJ15CA

• 600W Peak Pulse Handling for superior surge absorption

• Bidirectional Protection for versatile AC/DC use

• Ultra-Fast Response Time (less than 1 picosecond)

• Low Clamping Voltage minimizes stress on downstream components

• SMB Surface-Mount Package ideal for compact PCB designs

• RoHS Compliant and Lead-Free

These features make the SMBJ15CA ESD Suppressors/TVS Diodes a trusted component in high-reliability circuit protection designs.

3. Applications of SMBJ15CA

The SMBJ15CA is widely used in electronics that require strong circuit protection:

• LED Lighting Systems

• Network Routers & Modems

• Industrial Automation Devices

• DC Power Supplies

• Automotive Electronics

• Consumer Electronics (TVs, Set-top Boxes)

It effectively safeguards sensitive ICs, sensors, and power lines from ESD and transient voltages.

4. Wiring and Connection Overview

Standard wiring for SMBJ15CA bidirectional TVS diode:

[Protected Line] ——|>|—— GND
                     SMBJ15CA
[Protected Line] ——|<|—— GND

Mounted between the signal line and ground, the diode clamps dangerous spikes before they reach the protected circuitry.

5. Use Case Scenario: ESD Protection in LED Display Boards

Scenario: An electronics integrator faced recurring failures in outdoor LED signage due to ESD during thunderstorms.

Problem: Conventional diodes were insufficient for repeated exposure to surge conditions.

Solution: The SMBJ15CA by Juxing offered better clamping and higher pulse power handling.

Result: System longevity improved, and failures reduced by over 80%, making it a reliable part of their circuit protection solution.

6. Download Datasheet for SMBJ15CA

Looking for full electrical specifications and thermal ratings?

Download SMBJ15CA Datasheet from Xon Electronics

Get datasheet access for all compliance, clamping curves, and packaging details.

7. Why Buy from Xon Electronics?

Shop SMBJ15CA ESD Suppressors/TVS Diodes by Juxing from Xon Electronics and enjoy:

• 100% Authentic Components
• Worldwide Shipping to USA, India, Australia, Europe & more
• Volume Pricing for OEMs and EMS partners
• Tech Support for Design & Integration
• Safe Online Checkout & Global Warranty

Trusted partner for your circuit protection needs!

8. FAQs – SMBJ15CA ESD Suppressors/TVS Diodes

Q1. What type of diode is the SMBJ15CA?
It is a bidirectional TVS diode designed for transient voltage and ESD protection.

Q2. What is the peak pulse power rating?
It supports 600W at 10/1000µs waveform.

Q3. Can it protect both AC and DC lines?
Yes, the bidirectional nature makes it ideal for AC/DC circuit protection.

Q4. What industries use this component?
Automotive, telecom, industrial controls, and LED systems.

Q5. Where can I buy it globally?
Order now from www.xonelec.com — shipping to USA, India, Australia, Europe, and beyond.

Conclusion

The SMBJ15CA ESD Suppressors/TVS Diodes by Juxing Electronic Technology deliver powerful surge absorption in a compact, RoHS-compliant package. Designed for robust circuit protection, these diodes offer unmatched speed, protection, and versatility. Available now at Xon Electronics with fast global shipping to USA, India, Australia, Europe, and other countries. Get the protection your design deserves with SMBJ15CA.
