Overview of SN74AVC4T245PWR by Texas Instruments

The SN74AVC4T245PWR Translation - Voltage Levels by Texas Instruments supports data translation between 1.2V to 3.6V voltage levels and is housed in a compact TSSOP-16 package. Its direction-controlled functionality makes it highly suitable for synchronous and asynchronous communication systems that require efficient logic level interfacing.

Technical Specifications

• Part Number: SN74AVC4T245PWR

• Function: Voltage Level Translator (Bidirectional)

• Operating Voltage Range A Side (VCCA): 1.2V – 3.6V

• Operating Voltage Range B Side (VCCB): 1.2V – 3.6V

• Direction Control: Enabled via DIR pin

• Data Rate: Up to 380 Mbps (Push-Pull)

• Package Type: TSSOP-16

• Temperature Range: -40°C to +85°C

• ESD Protection: 2000V HBM

• Manufacturer: Texas Instruments

• RoHS Compliant: Yes

Key Features of SN74AVC4T245PWR Voltage Level Translator

1. Wide Voltage Range Compatibility

   • Supports translation between any two logic levels from 1.2V to 3.6V.

2. High-Speed Operation

   • Provides fast data rates up to 380 Mbps for robust communication performance.

3. Bidirectional Data Flow

   • Direction-controlled via the DIR pin for both synchronous and asynchronous systems.

4. Compact TSSOP-16 Package

   • Ideal for space-limited designs in portable and embedded devices.

5. Robust ESD Protection

   • Built-in ESD protection enhances durability and reliability in critical systems.

Applications of SN74AVC4T245PWR Voltage Translator

1. Mobile Devices

   • Facilitates communication between microcontrollers and low-voltage peripherals.

2. Consumer Electronics

   • Used in smart TVs, media players, and digital cameras for interfacing logic components.

3. Industrial Systems

   • Supports data translation in automation and control equipment.

4. Communication Equipment

   • Ensures reliable interfacing between multiple communication modules and standards.

5. Computing Systems

   • Bridges voltage differences in motherboards, memory controllers, and SoCs.

Circuit Integration / Wiring Example

In a typical application:

• VCCA and VCCB are connected to the respective voltage domains.

• DIR pin is used to control the direction of signal flow.

• OE (Output Enable) allows or disables the bus transceiver for flexible control.

This makes the SN74AVC4T245PWR Translation - Voltage Levels by Texas Instruments perfect for interfacing microcontrollers operating at 1.8V with peripherals running at 3.3V or vice versa.

Use Case Scenario – Bridging a 1.8V MCU with 3.3V Sensor

Scenario: A development team needs to connect a 1.8V microcontroller to a 3.3V environmental sensor in a wearable device.

Implementation:
They use the SN74AVC4T245PWR Translation - Voltage Levels by Texas Instruments for clean and reliable bidirectional communication.

Outcome:

• Stable data exchange between voltage domains

• High-speed operation with low power use

• Compact design integration in the device

Where to Buy SN74AVC4T245PWR?

You can purchase SN74AVC4T245PWR Translation - Voltage Levels by Texas Instruments from Xon Electronics. We offer global delivery to the USA, India, Australia, Europe, and other regions with fast service and genuine sourcing.

Conclusion

For high-performance, low-voltage signal conversion, the SN74AVC4T245PWR Translation - Voltage Levels by Texas Instruments is an exceptional choice. It supports wide voltage compatibility, high data rates, and robust performance for use in everything from smartphones to industrial systems. Order now from Xon Electronics and enhance your circuit design with reliable logic level translation.
