SWPR-001T-P025 Crimp Terminals by JST

SWPR-001T-P025 Terminals by JST – High-Reliability Crimp Contacts for Compact Wiring Systems

The Terminals SWPR-001T-P025 by JST are precision-engineered crimp terminals designed for secure and efficient wire-to-board or wire-to-wire connections in compact electronic assemblies. These tin-plated contacts are part of JST’s renowned SWPR series, offering exceptional conductivity, reliable mating, and excellent retention force in confined spaces. Built for performance in consumer electronics, automotive systems, and industrial devices, the Terminals by JST ensure long-term connectivity with minimal insertion resistance and superior durability.

In this blog, we’ll explore the technical specifications, key features, real-world applications, installation overview, and why you should choose Xon Electronics as your global supplier.

Technical Specifications of SWPR-001T-P025

• Manufacturer: JST

• Part Number: SWPR-001T-P025

• Series: SWPR

• Contact Type: Crimp Terminal

• Wire Gauge Range: 32 to 28 AWG

• Contact Plating: Tin over copper alloy

• Mounting Type: Free-hanging (Crimped to Wire)

• Rated Current: Up to 1A

• Operating Temperature: -25°C to +85°C

• Category: Connectors, Terminals by JST

These crimp terminals are designed for precision electronic systems where space, reliability, and electrical contact quality are critical.

Key Features of SWPR-001T-P025 Terminal

• Ultra-Compact Design – Ideal for high-density harnesses and miniature connectors

• Reliable Crimp Contact – Ensures stable electrical and mechanical connection

• Tin-Plated Finish – Enhances corrosion resistance and conductivity

• High Retention Strength – Maintains secure fit in connector housing

• RoHS Compliant – Environmentally friendly and globally approved

With these advantages, the SWPR-001T-P025 Terminals by JST are a leading solution for signal, data, and low-power connections in space-constrained devices.

Applications of Terminals by JST

The Terminals by JST are widely used in electronics where miniaturization and dependable connectivity are required:

• Consumer Electronics (Headphones, Cameras, Wearables)

• Automotive Control Units and Dashboards

• Battery Packs and Smart Chargers

• Medical Monitoring Devices

• Embedded and IoT Systems

• Robotics and Control Boards

The SWPR-001T-P025 Terminals by JST provide consistent performance in both static and dynamic environments, supporting signal integrity even in mobile and high-vibration systems.

Crimping and Assembly Overview

Proper installation of these terminals ensures optimal connection quality:

1. Strip insulation from wire (28–32 AWG)

2. Insert wire into crimp barrel of terminal

3. Use a JST-approved crimping tool for accurate crimp pressure

4. Insert the terminal into the appropriate JST housing

5. Confirm retention and continuity via pull test or inspection

These steps guarantee low-resistance contact and long-lasting durability in assembled harnesses.

Use Case Scenario: Wire Harness in Compact IoT Sensor

Scenario: A startup developing compact IoT sensors needed micro crimp terminals for board-to-wire connections without risking signal drop.

Problem: Previous contacts lacked insertion precision and loosened over time.

Solution: The SWPR-001T-P025 Terminals by JST delivered secure crimping, excellent contact retention, and low-profile design.

Result: Improved product reliability, reduced maintenance, and successful high-volume integration.

This practical example shows why engineers trust Terminals by JST in mission-critical electronic assemblies.

Download Datasheet for SWPR-001T-P025

Need complete mechanical drawings, crimp specifications, or compatibility info?

[Download SWPR-001T-P025 Datasheet from Xon Electronics]

Why Buy from Xon Electronics?

Xon Electronics provides a wide selection of genuine Terminals by JST, including the SWPR-001T-P025, with:

• 100% Authentic JST Components
• Global Shipping – USA, India, Australia, Europe & more
• Bulk Availability for OEMs and Harness Manufacturers
• Technical Support for Assembly and Compatibility
• Fast, Safe, and Easy Online Ordering

Partner with Xon Electronics for high-quality connectivity solutions from JST.

Conclusion

The SWPR-001T-P025 Terminals by JST are compact, reliable, and precision-engineered for modern electronic assemblies. From consumer electronics to automotive control systems, these crimp contacts offer secure mating, minimal resistance, and superior long-term performance. Now available at Xon Electronics with global delivery to the USA, India, Australia, Europe, and other countries.
