TDA01H0SB1R DIP Switch by C&K – Compact 1-Position Switch

TDA01H0SB1R DIP Switches/SIP Switches by C&K – Compact, Reliable Board-Level Switching

The DIP Switches/SIP Switches TDA01H0SB1R by C&K are precision-engineered switches designed for low-profile, board-level configuration in digital electronics. These 1-position DIP switches offer reliable contact, long cycle life, and compact design—making them ideal for address settings, function control, and system configuration. The DIP Switches/SIP Switches by C&K are widely trusted across telecommunications, industrial control systems, and consumer electronics for their quality and consistency.

In this blog, we’ll explore technical specifications, top features, typical applications, mounting overview, and why Xon Electronics is your go-to supplier for global orders.

Technical Specifications of TDA01H0SB1R

Manufacturer: C&K
Part Number: TDA01H0SB1R
Switch Type: DIP Switch
Number of Positions: 1
Actuator Style: Raised Slide
Mounting Type: Through-Hole
Contact Rating: 25 mA @ 24V DC
Contact Resistance: = 100 mO
Operating Temperature: -40°C to +85°C
Insulation Resistance: = 100 MO
Category: DIP Switches/SIP Switches

Designed for simple, manual configuration and long-lasting performance in PCB assemblies.

Key Features of TDA01H0SB1R DIP Switches

Compact 1-Pole Design – Ideal for space-constrained boards
Raised Actuator – Easy to toggle with fingertip or tool
Reliable Gold Contacts – Prevents oxidation, ensures consistent signals
Long Mechanical Life – Rated for 2,000+ operations
RoHS Compliant – Environmentally safe and lead-free

With a strong blend of durability and compactness, TDA01H0SB1R DIP Switches/SIP Switches by C&K are ideal for manual system configuration.

Applications of TDA01H0SB1R DIP Switches

The TDA01H0SB1R DIP Switches/SIP Switches by C&K are widely used in:

Communication Devices
Industrial Control Panels
Security and Access Systems
Networking Equipment
Home Automation Boards

Whether setting an address or toggling a system function, these DIP Switches/SIP Switches by C&K deliver reliable mechanical and electrical performance.

Mounting and Configuration Guide

To install:

Insert through-hole leads into the PCB
Solder manually or via wave soldering
Toggle the raised slide actuator to ON/OFF positions for configuration

These DIP Switches/SIP Switches by C&K are easy to integrate and require no special tools or programming—ideal for fast field adjustments.

Use Case Scenario: Networking Device Configuration

Scenario: A telecom OEM needed a simple way to set hardware IDs for their network routers.

Problem: Complex programmable options slowed down the production line.

Solution: The TDA01H0SB1R DIP Switches/SIP Switches by C&K provided a mechanical, quick-select solution.

Result: Faster assembly, simplified testing, and easier user configuration.

Download Datasheet for TDA01H0SB1R

Need layout dimensions or electrical specs?

[Download the TDA01H0SB1R Datasheet from Xon Electronics]
(Insert product link when available)

Why Buy from Xon Electronics?

Xon Electronics provides genuine TDA01H0SB1R DIP Switches/SIP Switches by C&K with:

OEM-Certified Components
Worldwide Shipping – USA, India, Australia, Europe & more
Bulk Stock for OEMs and Assemblers
Technical Help for Design Integration
Secure, Easy Online Checkout

Visit www.xonelec.com and equip your PCBs with reliable DIP Switches/SIP Switches by C&K.

Conclusion

The TDA01H0SB1R DIP Switches/SIP Switches by C&K offer compact design, long life, and reliable performance for PCB configuration. Whether you're building control panels, routers, or embedded systems, these switches deliver simplicity and consistency. Available now at Xon Electronics with fast global shipping to the USA, India, Australia, Europe, and beyond.
